Stainless Steel Welded Pipe,304 Welded Steel Pipe

US$ 480 - 660 MOQ: 5 Metric Tons

Key Specifications

Standard:

Grade:

Thickness:

8, 60

Tianjin Xinyue Industrial And Trade Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Tianjin Port

Delivery Detail:

Delivery time depends on order quantity.

Thickness 8, 60

Section Shape Round

Outer Diameter 355.6 - 1828.8 mm

Place of Origin Tianjin, China

Secondary Or Not Non-secondary

Application Structure Pipe

Technique Cold Rolled

Certification BSI

Surface Treatment Galvanized

Special Pipe API Pipe

Alloy Or Not Non-alloy

Stainless steel welded pipe,304 welded steel pipe

Detail instruction about the stainless steel welded pipe

1 Product Specification

LSAW steel pipe (OD: 355.6mm to 1626mm) with thickness 8-50mm

2 Standard

API 5L PSL1/PSL2: GR B, X42, X52, X56, X60, X65, X70, X80

ASTM A53: GR A, GR B

ASTM A252: GR 1, GR 2, GR 3

EN: S235JRH, S275, S355JOH, S355J2H, S420, S460....BS, JIS, DIN, GB and so on.

3 Stainless steel welded pipe

Usage	Used for low pressure liquid delivery, such as water, gas, and oil.
LSAW	Longitudinal Submerged-Arc Welded Steel Pipe
Process	LSAW - UO(UOE),RB(RBE),JCO(JCOE,COE) DSAW -Double Submerged arc welded
Shipping	Bulk Carriers
Standard	API 5L, API 5CT, ASTM 53, EN10217, DIN 2458. IS 3589, GB/T3091, GB/T9711
Certificate	API 5L PSL1 / PSL2, API 5CT
Out Diameter	219mm – 1820mm(8"-72")
Wall Thickness	5.0 - 50mm
Length	6 – 12m
Steel Grade	API 5L: GR B, X42, X46, X56, X60, X65, X70 ASTM A53: GR A, GR B, GR C EN: S275, S275JR, S355JRH, S355J2H GB: Q195, Q215, Q235, Q345, L175, L210, L245, L320, L360- L555
Surface	Fusion bond Epoxy coating, Coal Tar Epoxy, 3PE, Vanish Coating, Bitumen Coating, Black Oil coating as per customer’s requirement
Test	Chemical Component Analysis, Mechanical Properties (Ultimate tensile strength, Yield strength, Elongation), Technical Properties (Flattening Test, Bending Test, Blow Test, Impact Test), Exterior Size Inspection, Hydrostatic Test.
Mill Test Certificate	EN 10204/3.1B
