220v high efficiency waterproof ventilation fans 2350rpm
- 150000 Piece / Pieces per Month
- Shanghai/Ningbo
- T/T Credit Card
Product Details
Electric Current Type: | AC | Mounting: | Other, Horizontal or vertical installation | Blade Material: | Other, Steel plate,surface treatment |
Place of Origin: | Zhejiang, China | Brand Name: | hangyan | Model Number: | YWF2E-400 |
Voltage: | 220V | Power: | 530W | Air Volume: | 6480m³/h |
Speed: | 2350r/m | Certification: | CCC, CE |
Product Description
Shape description
Model Description
YWF | 2 | E | - | 400 | S | - | 5 | L | - | G |
1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 |
1.YWF-External Rotor Axial Fan
2.Motor pole number:2-2poles,4-4poles.6-6poles,8-8poles
3.D:3-phases motor,E-single-phase motor
4.Blade diameter:200-blade diameter is 200mm
5.Wind code:S-induced draft,B-blow
6.Blade number:5-5blades
7.Wind leaf shape:L--falciform,F--aquare type,LT--continuum
8.Fan type:G-pipeline gaotong, A-short barrel, Fa-terms of frame short
barrel, Fg-aspects box Gaotong,W-meshenclosure type.
Detailed description
YWF External Rotor Axial Fan is a new product developed by our company by combining technology and talent advantages of many domestic colleges through repeated research and trail production. The impeller is directly fixed on the excircle to make axial size smaller. Its successful development is a key breakthrough of axial flow fan and achieves internationally advanced level.
These fans are featured by high efficiency, whole sealing, low noise and vibration, short axial size and maintenance prevention, so it has wider applicable fields, can replace the conventional axial flow fan, and also can be used for kitchens, industrial and mining factories and other places with serious oil, soot and dust.
Operating Environment: Elevation: below 4,000m, air humidity: less than 90ºC and ambient temperature: -25ºC~+60ºC for general products, products used in unconventional environment also can be customized.
About our company
The product has passed the European CE authentication and the Chinese CCC authentication.The good quality of our products has won the customer’s trusting all over the world.
Wholeheartedly provides the high quality product and the good service for the customer.
Main Marks:
product certification: CCC,CE,
