Borun Mould Co.,Ltd Breif Introduction:
1.Manufacturer locates in Changsha with more than 10 years production experience.
2.Strict implementation of ISO9001:2008 Standard
3.Advanced technology, Stable quality and Powerful productivity
4.Has obtained 3 utility model patents
5.The professional team and first-rate service
6.Own export right
Parting Lock, mold component of parting lock
It can adjust friction between template and nylon sleeve through locking taper bolt. Special nylon material is used for the product. Thus, the product has good abrasion resisitance and heat resisitance. Although heat resisitant temperature of nylon sleeve is 150°c. it will cause durability of nylon sleeve reduce for continuous locking stress of taper bolt in actual use process. Please use it below 80°c.
| Type | Size | |||||
| D | d1 | M | B | L | H | |
| PL 10 | 10 | 8.5 | M5 | 4 | 18 | 3 |
| PL 12 | 12 | 11 | M6 | 5 | 20 | 3.5 |
| PL 13 | 13 | 11 | M6 | 5 | 20 | 3.5 |
| PL 16 | 16 | 14 | M8 | 6 | 25 | 4 |
| PL 20 | 20 | 16 | M10 | 8 | 30 | 5 |
Installation method:
Embed nylon sleeve in template of moving die about 3mm. Implement rough finishing on inner surface of template hole of fixed die and implement filleting R of insertion mouth of template surface. If chamfer C is implemented, its durability will reduce.
→The basis of installation aperture tolerance shall be according to JIS H7.
Packing and Transportation:
Borun Mould Co.,Ltd Exhibition and Certificates:
Contact person: Ms Zoe Mao
Mobile: 0086-13600425319
Tel: 0086-731-88908466
Fax: 0086-731-88886632
Skype: borun mould
