Audio-Tracking Video Cnferencing Camera dedicated camera uses a 1/2.7 inch HD CMOS Image Sensor, 2 Million Pixels, HD Camera
ATC03HD high-definition video conferencing camera is the industry-leading video conferencing system dedicated camera uses a 1/2.7 inch HD CMOS image sensor, 2 million effective pixels, used in conjunction with any codec, as well as other systems, the high quality of the output,high-resolution images. Built-in 18x optical zoom lens, the output ratio of 16: 9 images, and high-speed, mute pan / tilt operation shooting, and large areas of the object and the disturbance is very small.It also has auto focus / auto exposure, 128 position preset position, external / remote control, and more convenient features. It is ideal for video conferencing, distance learning and corporate training.
(1)Support a variety of formats from SD to HD 1080, via the menu / control command to switch, Switching without having to restart the machine;
(2)18x optical zoom and 4x digital zoom;
(3)Supports the HD-SDI interface, DVI-I interface (adapter YPbPr, HDMI, DVI-D, VGA, etc.), convenient and flexible;
(4)Support being installed, mounted on the ceiling;
(5)Facilitate visualization menu operation, to simplify complex DIP switch control, simplify user operations complexity;
(6)Support a variety of control methods: RS-232, RS-485/422;
(7)Support the VISCA / PELCO-D / Pelco-P protocol.
Parameter Name | HD Camera ATC03HD |
Image pickup device | HD: 1080p60,1080p50,1080p30,1080p25,1080i60,1080i5 |
Electronic Shutter | 1/2 to 1/10000 seconds |
Minimum illumination | 12Lx(50IRE,F1.6) |
Horizontal viewing angle | Maximum horizontal viewing angle of 55.2 degrees |
Zoom | 18x optical zoom, 4x digital zoom |
SNR (S / N) | ≥ 50dB |
Synchronization | Internal synchronization |
Backlight compensation | OFF / ON Auto Backlight Compensation |
Rotation speed | Horizontal (0.1 ° to 200 ° / sec) vertical (0.1 ° ~ 150 ° / sec.) |
Angle range | Horizontal ± 150 ° , vertical -30 to 90 ° |
Prese | 256 |
Video output interface | DVI interface (HD, can be converted to DVID, |
interface (HD), CVBS Interface (SD) | |
Multi-channel video output | Supports 2-way highdefinition and |
Control Protocol | PELCO-D,PELCO-P,VISCA |
Control Interface | RS485/422,RS232 |
Communication baud rate | 9600/19200/38400 bps |
Address range | 0 ~ 255 |
Temperature | Operating temperature: 0 ℃ ~ +50 ℃ , Storage |
Power Consumption | 12VDC,<10W |
Size | 260×160×140 mm ( L×W×H ) |
