Introduction:
8x2 RGB matrix rca multimedia router switch is the high performance meets high resolution computer signal switching matrix switching equipment .
Allows the computer and audio signals switch synchronously or asynchronously .
Compatible with multiple control modes :CRV-NET bus, RS232, key action, software packages, infrared remote control .
Widely used in multimedia Conference, radio and television engineering, command and control centers, and other occasions .
Application:
Widely used in multimedia conferencing works, radio and television engineering, command and control centers and other occasions.
Features:
.Video bandwidth up to 450MHz (-3dB), resolution:2048x1536@85Hz.
. Provide save preset option, the current switch status power off memory.
. LCD displays the switch status in real time, and to query the current matrix to input or output channel status.
. Front panel with touch-key operation interface
. Compatible with multiple control modes: CRV-NET bus, RS232, key action, software packages, infrared remote control.
Technical specification:
Composite analog signals |
Analog audio signal |
||
Video bandwidth |
450MHz(-3dB) |
Audio bandwidth |
150MHz(-3dB) |
Input signal |
RGBHV, RGBS,RGsB,RsGsBs |
Input signal |
Stereo signal |
Input level |
5 BNC |
Input level |
RCA/3.8mm screw locking device |
RGB input connector |
0.5Vp-p~2.0Vp-p |
Input max connector |
+19.5dBu |
RGB input impedance |
75Ω |
Input impedance |
>10K Ω |
HV input connector |
0.5V~5.0VP-P |
Output signal |
Stereo signal |
HV input impedance |
510Ω
|
Output level |
RCA/3.8mm screw locking device |
Output signal |
RGBHV,RGBS,RGsB,RsGsBs |
Output max connector |
+19.5dBu |
Output level |
5 BNC
|
Output impedance |
>50 Ω |
RGB output connector |
0.5Vp-p~2.0Vp-p |
Frequency response |
20Hz-20KHz,+0.05dB |
RGB output impedance |
75Ω |
Signal-to-noise ratio |
>90dB |
HV output connector |
0.5V~5.0Vp-p |
Stereo channel separation |
>80dB @1KHz |
HV output impedance |
75Ω
|
Common mode rejection radio |
>75dB@20Hz~20kHz |
Return loss |
<-40dB@5MHz |
|
|
Horizontal frequency response |
15KHz~145KHz |
|
|
Vertical frequency response |
30Hz~170Hz |
|
|
Item No. Des
.RGB16*4 16*4 matrix switcher with RS232
.RGB16*8 16*8 matrix switcher with RS232
.RGB16*16 16*16 matrix switcher with RS232
CE, ROHS, ISO9001:1998
Diagram
