Specifications
SVC-10000VA 3P Full Automatic Voltage RegulatorSVC-10000VA 3P Full Automatic Voltage Regulator
Application:
SVC-10000VA 3P Full Automatic Voltage Regulator
SVC-10000va 3P Full Automatic Voltage Regulator is one kind of our dominant products, made up of contact auto voltage regulator, servo motor, automatic control circuit, etc. When the power network voltage fluctuates or the load varies, automaticsampling control circuit will send signal to drive the servo motor which can adjust the position of carbon brush of auto voltage regulator, then, the output voltage will be adjusted to rated value and get a steady state.
This voltage stabilizer is of common type, it has the function of connecting through the commercial power. Compared with other voltage stabilizers, it has the advantage of great variety, complete specification, nice appearance and obvious features of high efficiency, no wave distortion,reliable performance, working continually for long time, besides, it is provided with short time delay and over voltage protection, and the long time delay and under voltage protection also can be set according to user requirement. This product is an ideal stabilized voltage supply, widely used in any locations requiring electricity and ensures your power device can run normally.
For office equipment, testing equipment, medical equipment,industrial automation equipment, household appliance, lighting system,communication system, etc.
Provide kinds of electrical appliances with abundant electric powermeeting different requirements
Technic data:
Input voltage | 150V-250V | Ambient temperature | -10°C ~+40°C |
Output voltage | 220V±3%,110V±3% | Relative humidity | less than90% |
Frequency | 50Hz/60Hz | Waveform distortion | Non-lack fidelity waveform |
Response time | less than 1s(against 10% input voltage deviation) | Power Factor COSΦ | 0.8 |
Efficiency | more than 90% | Insulation resistance | more than 5MΩ |
Outline and Packing
Type | Outline(cm) | Weight(Kg) | Qty/CTN | ||
L | W | H | |||
SVC-500VA | 18.5 | 15 | 12.5 | 17 | 4PCS |
SVC-1000VA | 21 | 18 | 14.5 | 20 | 4PCS |
SVC-1500VA | 21 | 18 | 14.5 | 25 | 4PCS |
SVC-2000VA | 27.5 | 23.5 | 18.5 | 7.8 | 1PC |
SVC-3000VA | 29 | 23 | 22 | 9.8 | 1PC |
SVC-5000VA | 45 | 24 | 18.5 | 14 | 1PC |
SVC-7500VA | 47 | 26 | 22 | 19.5 | 1PC |
SVC-10000VA | 47 | 26 | 22 | 24.5 | 1PC |
SVC-15000VA | 42 | 38 | 73 | 35 | 1PC |
SVC-20000VA | 42 | 38 | 73 | 68.5 | 1PC |
SVC-30000VA | 42 | 38 | 83 | 80 | 1PC |
SVC-5000VA | 28 | 30 | 46 | 19 | 1PC(Cabinet) |
SVC-10000VA | 44 | 32 | 56 | 31 | 1PC(Cabinet) |
