Specifications
1.Wide voltage range2.Input voltage display,output voltage display
3.Output delay time selectable
Specifications:
1)Input voltage:160-270V
2)Output voltage:220 10%
3)Phase:single-phase or three-phase
4)Frequency:50/60HZ
5)Ambient temperature:-5~+40c
6)Ambient humidity:less than 90%
7)Temperature rise(input voltage200v,output voltage 220v and rated load):less than 75°C
8)Insulation resistance:more than 3m at DC 500v
Specification of AVR |
SVC-500VA |
SVC-1000VA |
SVC-1500VA |
SVC-2000VA |
SVC-3000VA |
SVC-5000VA |
|
Input |
Phase |
Single phase |
|||||
Voltage |
AC 150V-250V/50V-130V |
||||||
Frequency |
50Hz/60Hz |
||||||
Output |
Voltage |
220V±3% / 110V±6% |
|||||
Capacity |
400W |
800W |
1200W |
1600W |
2400W |
4000W |
|
Frequency |
50Hz/60Hz |
||||||
Protection |
Low voltage |
AC 184V±4V |
|||||
Over voltage |
AC 246V±4V |
||||||
Time Delay |
3-7sec/3-7min Selectable |
||||||
Overload/short circuit |
YES |
||||||
Packaging |
Pcs per Carton |
4 |
1 |
||||
Shipping Wt.(Kg) |
16.6 |
21.35 |
23.15 |
7.9 |
11.45 |
20.8 |
|
Packing dimensions(mm) |
245*340*425 |
495*285*390 |
355*295*240 |
365*275*280 |
540*325*270 |
||
Efficiency |
AC-AC |
>95% |
|||||
Acoustic |
Noise level |
≤50dB |
|||||
Environment |
Temperature |
-5 to 40 |
|||||
Humidity |
20% to 90% |
||||||
QTY (pcs) |
20FT |
3200 |
2100 |
2100 |
1120 |
1120 |
600 |
