D.O.L LG Model Magnetic Contactor Starter With Plastic Body
Negotiable
MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
Kasan, KASAN/OEM
Model Number:
LE1-D Magnetic Stater
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo/Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Three Phase GMW-9MB,12MB,18MB,22MB,32MB Electric Magnetic StarterNegotiableMOQ: 1 Piece -
LE1-D 09/12/18/25/32/40 Old Type Magnetic Motor StarterNegotiableMOQ: 1 Piece
-
LA1DN11 Auxiliary Contactor Auxiliary Contact,contactor TelemecaniqueNegotiableMOQ: 1 Piece
-
New Type LA1-DN11 Auxiliary Contactor BlockNegotiableMOQ: 1 Piece
-
LX1-D Telemecanique Contactor Coil for Electrical ContactorNegotiableMOQ: 1 Piece
Place of Origin
Zhejiang, China
Brand Name
Kasan, KASAN/OEM
Model Number
LE1-D Magnetic Stater
Electricity Type
AC
Number of Pole
Other, 3, 3
Phase
3
Main Circuit Rating Voltage
500v
Specifications
D.O.L LG Model Magnetic Contactor Starter With Plastic bodyD.O.L LG Model Magnetic Contactor Starter With Plastic body
Feature:
1.far distance making,breaking circuit;frequently starting, controlling motor
2.safe,reliable performance
Application:
GMW(magnetic starter,magnetic switch,ac contactor) is mainly applied to circuit of AC 50 or 60Hz, voltage up to 550V for far distance making and breaking circuit and frequent start and control motor. It has the features of small volume, light weight, low power consumption, high efficiency,safe and reliable performance etc.
| Type | Selected AC Contactor | Selected Thermal Overload Relay | Rated Power KW/HP( AC-3 )IEC60947-4-1 GB14048.4 | Rated Current A(AC-3) IEC60947-4-1 GB14048.4 | Rated Heating Current Ith:(A) | Rated Insulated Voltage Ui:(V) | Auxiliary Contact AC-15 | Electrical/Mechanic Life (Million Times) | ||||||||||||||||
| Contact Arrangement | Rated Current (A)(AC-3) IEC60947-4-1 GB14048.4 | Rated Heating Current Ith:(A) | ||||||||||||||||||||||
| 200-220V |
380- 440V |
200-220V | 380-440V | Standard | Special | 200-220V | 380-440V | |||||||||||||||||
| KGMW-9P | KGMW-9 | KGMW-22 | 2.5/3.5 | 4/5.5 | 11 | 9 | 20 | 660 | 1NO+1NC | / | 1.6 | 0.95 | 16 | 1/5 | ||||||||||
| KGMW-12P | KGMW-12 | KGMW-22 | 3.5/4.7 | 5.5/7.5 | 13 | 12 | 20 | 660 | 1NO+1NC | / | 1.6 | 0.95 | 16 | 1/5 | ||||||||||
| KGMW-18P | KGMW-18 | KGMW-22 | 4.5/6 | 7.5/10 | 18 | 18 | 25 | 660 | 1NO+1NC | / | 1.6 | 0.95 | 16 | 1/5 | ||||||||||
| KGMW-22P | KGMW-22 | KGMW-22 | 5.5/7.5 | 11/15 | 22 | 22 | 32 | 660 | 1NO+1NC | / | 1.6 | 0.95 | 16 | 1/5 | ||||||||||
| KGMW-32P | KGMW-32 | KGMW-40 | 7.5/10 | 15/20 | 32 | 32 | 45 | 660 | 2NO+2NC | / | 1.6 | 0.95 | 16 | 1/5 | ||||||||||
| KGMW-40P | KGMW-40 | KGMW-40 | 11/15 | 18.5/25 | 40 | 40 | 50 | 2NO+2NC | / | 1.6 | 0.95 | 16 | ||||||||||||
