LC1-D18 Old Type Magnetic AC Contactor

LC1-D18 Old Type Magnetic AC Contactor thumbnail-1
LC1-D18 Old Type Magnetic AC Contactor photo-1
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
KASAN AC Contactor
Model Number:
LC1-D18 AC Contactor
Contact Supplier Request Quote Chat Now
Yueqing Kasan Electric Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
NINGBO/SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Zhejiang, China
Brand Name KASAN AC Contactor
Model Number LC1-D18 AC Contactor
Electricity Type AC
Number of Pole 3
Phase 3
Main Circuit Rating Voltage Other, 220/380/415/660V
Main Circuit Rating Current Other, 18A

LC1-D18 Old Type Magnetic AC Contactor





1.Old type magnetic AC Contactor

2. Contacts no: 3P+NO+NC

3. Frequency:50&60hz

4. Current Rating:18A

4.Used as: motor controller







silver contacts(%): A  B C D Grades for customer's choice.







KASAN CAN OFFER SMALL QUANTITY AS PER CUSTOMER'S NEEDS.





LC1-D series AC Contactor is suitable for using in the circuits up to the rated voltage 660VAC 50hz or 60hz,rated current up to 620A,for making,breaking,frequently starting&controlling the AC motor.Combined with the auxiliary contact block,timer delay & machine-interlocking device etc,it becomes the delay contactor,mechanical interlocking contactor,star-delta starter. With the thermal relay, it is combined into the electromagnetic starter. The products conforms to IEC60947-4-1 standard





KASAN PROVIDES EITHER OEM OR ODM SERVICE







SPECIFICATION



LC1-D18 Old Type Magnetic AC Contactor



Outline and mounting dimension



LC1-D18 Old Type Magnetic AC Contactor



Photos:



LC1-D18 Old Type Magnetic AC ContactorLC1-D18 Old Type Magnetic AC ContactorLC1-D18 Old Type Magnetic AC ContactorLC1-D18 Old Type Magnetic AC ContactorLC1-D18 Old Type Magnetic AC Contactor



LC1-D18 Old Type Magnetic AC Contactor

Yueqing KASAN Electric Co.,LTD, is one of the best manufacturer and exporter companies in Liushi,Wenzhou. We specialize in export various low voltage electrical products with over 50 series and more than 6000 specifications have been producing electrical goods for more than 10 years in this line, which also a BV assessed gold supplier on Alibaba.

Our Promise to customer:

   1.     Quality Guaranteed

   2.     Delivery time guarantee

   3.     Provide superior service to fit customer need



LC1-D18 Old Type Magnetic AC ContactorLC1-D18 Old Type Magnetic AC Contactor



LC1-D18 Old Type Magnetic AC ContactorLC1-D18 Old Type Magnetic AC Contactor



LC1-D18 Old Type Magnetic AC ContactorLC1-D18 Old Type Magnetic AC Contactor
