KNP Series - Fixed WireWound Resistors (Non-Inductive Optional)
Negotiable
MOQ: 5000 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
THUNDER
Model Number:
KNP
Type:
Fixed Resistor
Payment & Shipping
Payment Methods:
Port of Shipment:
GuangZhou
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
KNP Series - 15W Fixed WireWound Resistors 0.01% (Non-Inductive Optional) for LED Illumination ApplicationNegotiableMOQ: 500 Pieces -
KNP Series - 10W Fixed WireWound Resistors (Non-Inductive Optional) for LED Illumination ApplicationNegotiableMOQ: 500 Pieces
-
CH Series - 100W Fixed High Power WireWound Resistors (Non-Inductive Optional)NegotiableMOQ: 10 Pieces
-
CH Series - 50W Fixed High Power WireWound Resistors (Non-Inductive Optional)NegotiableMOQ: 10 Pieces
-
CH Series - 40W Fixed High Power WireWound Resistors (Non-Inductive Optional)NegotiableMOQ: 10 Pieces
Brand Name
THUNDER
Model Number
KNP
Type
Fixed Resistor
Technology
Wirewound
Package Type
Throught Hole
Resistance
0.01ohm ~ 30Kohm
Resistance Tolerance
0.01% ~ 5%
Rated Power
1/2W ~ 30W
Temperature Coefficient
300PPM
Operating Temperature
-55~155 Degree C
Specifications
20W WireWound Resistors (Non-Inductive Optional)- Superior Anti-Heat
- Superior Pulse
- High Reliable
- High Voltage
Characteristic
Dimension
How to order
Packaging & Shipping
Standard Packing : Plastic Pallet wrapped by water proof plastic film
Optional Packing : Strong Metal Pallet with wood cover to protect products withour damages during transportation.
Company Information
Thunder Group was established in Taiwan Taipei in 1971, which has produced resistors more than 40 years. We have provided our products around the world including Vishat Dale Electronics, Panasonic, and Funkushima Futaba. We believe our professional experience can offer you best quality resistors with the most competitive price and fast lead-time.
Thunder Group Location
Taipei Headquarters & Kaohsiung SMD Chip Resistor Factory
GuangZhou Factory
ShenZhen Factory
HuNan Factory
GabZhou Factory
Contact Us
Certifications
ISO 9001:2008
ISO 14001:2004
WireWound Resistors (Non-Inductive Optional)
| TYPE | RATED WATTS | DIMENSIONS(mm) | RESISTANCE RANGE(Ω) | |||
| D | L | H | d | |||
| KNP-1/2W | 1/2W | 3.2 | 9 | 28 | 0.6 | 0.1-510 |
| KNP-1W (KNP-2WS) | 1W | 4.5 | 11 | 28 | 0.65 | 0.1-820 |
| KNP-2W (KNP-3WS) | 2W | 5 | 15 | 28 | 0.8 | 0.1-2K2 |
| KNP-3W (KNP-5WS) | 3W | 6 | 17 | 28 | 0.8 | 0.1-5K |
| KNP-4W | 4W | 7.5 | 24 | 38 | 0.8 | 01-10K |
| KNP-5W | 5W | 7.5 | 24 | 38 | 0.8 | 0.1-15K |
| KNP-6W | 6W | 7.5 | 24 | 38 | 0.8 | 0.1-20K |
| KNP-8W | 8W | 8.5 | 32 | 38 | 0.8 | 0.1-5K |
| KNP-10W | 10W | 8.5 | 32 | 38 | 0.8 | 0.1-30K |
| KNP-12W | 12W | 8.5 | 37 | 38 | 0.8 | 0.1-33K |
| KNP-15W | 15W | 8.5 | 42 | 38 | 0.8 | 0.1-36K |
| KNP-20W | 20W | 8.5 | 52 | 38 | 0.8 | 0.1-47K |
Key Specifications/Special Features:
- Temperature coefficient of resistance: +/-300ppm/degrees Celsius
- Short time overload: +/- (2%+ 0.05 ohms)
- Dielectric withstanding voltage: no evidence of damage
- Insulation resistance: >1000M ohms
- Terminal strength: no evidence of damage
- Moisture load life: +/- (5%+ 0.05 ohms)
- Load life at 70 degrees Celsius: +/- (5%+ 0.05 ohms)
- Temperature cycling: +/- (2%+
- 0.05 ohms)
- Resistance to soldering heat: +/- (2%+ 0.05 ohms)
- Solderability: >95%
- Resistance to solvent: no evidence of damage
- Flameproof: no evidence of damage
- Key:
- Dimension (mm) = D
- Resistance range = R
- Power rating = P
- KNP1/2W; KNP1W(S):
- D: 9.0 +/- 1.0 (L); 3.2 +/- 0.5 (D); 0.7 +/- 0.05 (d); 28 +/-3 (H)
- R: 0.1 to 100 ohms
- P: 0.25W;
- 1W
- KNP1W; KNP2W(S):
- D: 12.0 +/- 1.0 (L); 4.5 +/- 0.5 (D); 0.8 +/- 0.05 (d); 32 +/- 3 (H)
- R: 0.1 to 100 ohms
- P: 1W; 2W
- KNP2W; KNP3W(S):
- D: 15.5 +/- 1.0(L); 5.0 +/- 1.0 (D); 0.8 +/- 0.05 (d); 35 +/- 3 (H)
- R: 0.1 to 120 ohms
- P: 2W; 3W
- KNP3W; KNP5W(S):
- D: 17.5 +/- 1.0 (L); 6.5 +/- 1.0 (D); 0.8 +/- 0.05 (d); 35 +/- 3 (H)
- R: 0.1 to 180 ohms
- P: 3W; 5W
- KNP5W:
- D: 24.5 +/- 1.0 (L); 9.0 +/- 1.0 (D); 0.8 +/- 0.05 (d); 32 +/- 3 (H)
- R: 0.1 to 300 ohms
- P: 5W
- KNP7W:
- D: 41.0 +/- 1.5 (L); 9.0 +/- 1.0 (D); 0.8 +/- 0.05 (d); 38 +/- 3 (H)
- R: 0.1 to 1.5K ohms
- P: 7W
- KNP 10W
- D: 41.0 +/- 1.5 (L); 9.0 +/- 1.0 (D); 0.8 +/- 0.05 (d); 38 +/- 3(H)
- R: 0.1 to 2.2K ohms
- P: 8W
- KNP 15W
- D: 53.0 +/- 1.5 (L); 9.0 +/- 1.0 (D); 0.8 +/- 0.05 (d); 38 +/- 3 (H)
- R: 0.1 to 3.3K ohms
- P: 10W
- Resistance tolerance: +/-1%, +/-2%, +/-5%, +/-10%
