MAIN TECHNICAL SPECIFICATION
Size: 8000mm × 2250mm × 2300mm
Total Weight: about 12KG
Main Motor Power: 18.5KW forming power is 7.5kw ; bending power is 4.0kw; cutting power is 4.0kw; conical power is 3.0kw
Working Speed: Straight sheet: 15m/min
Arch sheet: 13m/min
Sewing: 6m/min
Material of rollers: 45# steel, quenched HRC 58-62
Material of roller shafts: 45# steel, quenched HRC 58-62
Material of cutting blade: Cr12 steel (Taiwan Airline Technique)
Step of rollers: 8 steps
Thickness of the coil: 0.8-1.5mm
Gear/Spoket driving: 8 stations to form
Electric Standard: 380V / 50 HZ / 3 PHASE
Type of cutting: Roll-formed and length-set cutting
Ship Container: 40HC x 1
Operating factor of the panel: 66%
Proper span: ≤38m
Name |
Usage |
Amount |
Sewing machine |
As spare part |
1 |
Manual Decoiler |
Mount metal sheet roll |
1 |
Straight sheets cradle |
Plate supporter |
8 |
Arch sheets cradle |
Plate supporter |
8 |
Straight sheets side cradle |
Plate supporter |
8 |
Suspender |
Lifting |
3 |
Hanger |
Lifting |
8 |
Clamp |
Bait sheets |
8 |
Manual Super pliers |
Bait sheets |
2 |
VCD |
Teach customers how to produce |
2 |
Driving chains |
To roll the gears |
3M |
CHAIN HALF SECTION |
AS SPARE |
5 |
CHAIN WHOLE SECTION |
AS SPARE |
5 |
Designing software same as MIC |
To help you design K-span project |
1 |
Instruction book |
To guide you how to use the machine |
1 |
Manual calculator(electric sensing equipment) |
Measure the length by hand |
1 |
Switch |
As spare |
1 |
TOOL BOX |
AS THE TOOL FOR MAINTENACE |
1 PIECE |
ROLLING CRANDLE |
TO RISE AND FALL THE MACHINE |
2 |
Packaging: Important Components Wiped Anti Rust Oil, Rollers and Shafters covered by foam film, Hydraulic station, PLC control Box, Spare parts and some small parts
Packed in plywood box. All Components Fixed by steel wire with Container.
Payment Terms: 30%T/T after signed the contract,balanced before delivery
Warranty
1). One year, and we will provide the technical support for the whole life.
2).Training: the buyer should charge of visa, return ticket, food and accommodation
overseas and USD50/person/day for salary.
3). Need one technicians
4).Training time: one week (contains the time of installation and adjustment)
