Home > Manufacturing & Processing Machinery > Pharmaceutical Equipment & Machinery > Pharmaceutical Tablet Equipment > ZP-33F 35F 37F High Speed Tablet Press
ZP-33F 35F 37F High Speed Tablet Press
US$ 11,000 - 22,500
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Zhejiang, China
Brand Name:
JINDE
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
ZP-39F 41F High Speed Rotary Tablet PressUS$ 11,000 - 25,000MOQ: 1 Set -
ZP-29F 31F High Speed Tablet Press Machine, Mechanical Press Machine, Rotary Tablet PressUS$ 10,000 - 17,000MOQ: 1 Set
-
KX-250D Multifunctional Pillow Type Automatic Syringe Blister Packing MachineUS$ 7,500 - 16,000MOQ: 1 Set
-
KX-250D Multifunctional Pillow Type Automatic Plastic Spoon Packing MachineUS$ 7,500 - 16,000MOQ: 1 Set
-
KX-250D Multifunctional Pillow Type Automatic Spoon Wrapping MachineUS$ 7,500 - 16,000MOQ: 1 Set
Condition
New
Place of Origin
Zhejiang, China
Brand Name
JINDE
Model Number
ZP-33F 35F 37F
Type
Rotary Tablet Press
Production Capacity
160000 (p/h)
Max. Pressure(KN)
80kn
Max. Tablet Thickness(mm)
17mm
Max. Tablet Diameter(mm)
13mm(Irregular 16)
Voltage
380V 50HZ (220V 60HZ)
Power(W)
3kw
Weight
2000kg
Dimension(L*W*H)
1300X1200X1750 mm
Certification
CE
After-sales Service Provided
Engineers available to service machinery overseas
Specifications
high speed tablet press1.CE,GMP
2.Made of stainless steel
3.With Plexi-glass perspective
4. Over-loading protection
high speed tablet press
Application
Use to various normal or abnormity tablets pressing (include double printed ),it’s the best choice for the industries pharmaceutical ,Chemical, Foodstuff, Plastic Electronic producing and so on
Feature
- The material contact parts is made of stainless steel ,the surface of turntable deal with polished to prevent cross pollution which meet the GMP requirement
- It is equipped with Plexi-glass perspective window for tablet producing observation .Each perspective window could be fully open and easy for cleaning and maintenance
- Driving system is equipped with oil box and running under oil ,easy for heat dissipation and durable ,non-pollution
- It adopts import frequency timing with hydraulic system
- With the over-loading protection
- The punch Die of that machine is current used to ZP19 ZP33 type
Technical parameters
Die Amount |
33stations |
35 stations |
37 stations |
Max Pressure |
80kn |
80kn |
80kn |
Max Filling Depth |
17mm |
17mm |
17mm |
Max Pressure Diameter |
13mm(Irregular 16) |
13mm(Irregular 16) |
13mm(Irregular 16) |
Max Tablet Thickness |
7mm |
7mm |
|
RPM |
16-36(r/min) |
16-36(r/min) |
16-36(r/min) |
Capacity |
140000 (p/h) |
150000 (p/h) |
160000 (p/h) |
Power |
3Kw 380V 50HZ (220V 60HZ) |
3Kw 380V 50HZ (220V 60HZ) |
3Kw 380V 50HZ (220V 60HZ) |
Overall Dimension |
1300×1200×1750 mm |
1300×1200×1750 mm |
1300×1200×1750 mm |
weight |
2000kg |
2000kg |
2000kg |
Some parts of the machine
Samples
Send Inquiry to This Supplier
Business Type
Manufacturer
Year Established
2013
Factory Size
10,000-30,000 square meters
Total Employees
11 - 50 People
