WS2812B Individually Addressable SMD5050 RGB Pixel LED Flexible Strip DC5V

Name: WS2812B Individually Addressable SMD5050 RGB Pixel LED Flexible Strip DC5V
Brand: Ipixel
SKU: 134757041
Availability: InStock

US$ 8.5 - 11 MOQ: 1 Meter

Key Specifications

LED Light Source:

RGB

Type:

Flex LED Strips

Input Voltage(V):

DC5V

Shenzhen Shiji Lighting Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen Yantian

Delivery Detail:

Delivery time depends on order quantity.

LED Light Source RGB

Type Flex LED Strips

Input Voltage(V) DC5V

Lamp Power 14.4W

Lamp Luminous Flux(lm) R:24000 G:42000 B:12000

Color Temperature(CCT) RGB

Working Temperature(℃) -40, 60

Working Lifetime(Hour) 50000

Lamp Body Material Copper

Certification CE

Emitting Color Other, full color

Brand Name Ipixel

Model Number SJ-10060-WS2811

Specifications

DC5V 14.4W/M (MAX )
WS2811 IC builted in 4 pin 5050 LEDs /WS2812B LEDs
DMX , Artnet , Arduino and SD Card controller .

WS2812B Digital RGB LED Flexible Strip

Technical Details

10mm wide for flexible PCB board, 16.7mm long per segment can be cutted .

60 LEDs per meter

Workable IP65 silicon tube weatherproof casing

5VDC power requirement (do not exceed 6VDC) - no polarity protection

1 integrated RGB LEDs per segment, individually controllable

LED wavelengths: 630nm/530nm/475nm

Connector: 3-pin JST SM

LED type:	SMD 5050 RGB	Material:	Super slim flexible PCB, 3M tape at back
Voltage:	DC5V	Starting time(S):	<1.2S
Color:	Full color changing	FrequencyRange(Hz):	50/60hz
LED Qty.:	60 pcs/m	Optical decay rate(%):	50000hours<5%
Beam angle:	>120°	RA:	RA70-75/RA>80
IP rate:	IP44,IP65,IP67,IP68	Usage:	Decoration
Flexibility:	360°	Work Temperature/RH:	-25°C - 50°C
Luminous Flux:	660-720LM/m for 60led/m,	Storage temperature/RH:	-40°C - 85°C
Color Temperature:	2800K-7200K	Customized:	Yes
Power:	14.4W/m 5050 60smd	Brand	IPIXEL or OEM
