SJ-100144-2811 Ws2812b Pixel Strip

SJ-100144-2811 Ws2812b Pixel Strip thumbnail-1
SJ-100144-2811 Ws2812b Pixel Strip photo-1
US$ 15 - 35 MOQ: 10 Meters
Key Specifications
Get Latest Price
LED Light Source:
epistar smd5050 / ws2812b
Type:
Flex LED Strips
Input Voltage(V):
5
Contact Supplier Request Quote Chat Now
Shenzhen Shiji Lighting Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen Yantian
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
LED Light Source epistar smd5050 / ws2812b
Type Flex LED Strips
Input Voltage(V) 5
Lamp Power 34.56
Color Temperature(CCT) Pixel
Working Temperature(℃) -30, 50
Working Lifetime(Hour) 50000
Lamp Body Material Copper
Certification CE
Emitting Color Changeable
Place of Origin Guangdong, China
Brand Name SJ / iPixel
Model Number SJ-100144-2811 / SJ100144-WS2812B

Specifications

144 pixels ws2812b led strip
DC5V 34.5W/M
WS2811 built into 5050
2 years warranty
addressable

144 pixels ws2812b led strip



Description:

 Smart RGB Pixel Strip light---ws2812b IC built-in ws2811 Digital LED Strip

--Each smd 5050 (ws2812b)has an IC(ws2811) inserted in,Each LED individually address controlled.

--You can design many different  lighting effects or animations you want.

--This is the highest resolution one for the moment!

--Controller, power supply are available!

-- programmable addressable 144 pixels ws2812b led strip



Feature:

Products Name

 WS2812b Led pixel strip

Model NO.

SJ-10144-2811

Power Consumption

34.56W/Meter

Work Voltage

DC5V

IC model

ws2811 built into ws2812b 5050

LED Qty

144pcs SMD5050RGB

PCB Color

black/white PCB

Dimension

L1000*W14*H3mm

Waterproof Grade

IP20 / IP44 / IP65 / IP66 / IP67

Work Temperature

-40-+60°C

Life-span

50,000H

Certificate

CE&RoHS

Warranty

2 years



Control System:



1. Offline control: SJ-T-1000s, SJ-8000C for off-line working, can control max 2048 Pixels, 8192 Pixels.

2. Online control: SJ-T-200K, 300K for on-line working, can control max 4096,8192 pixels.

3. Compatible with Arduino, DMX 512.



Connection:
1) Signal wire: DC+, DAT, GND
2) DC+ and GND connect to power supplier;DAT and GND connect to controller
3) Relative Controller: SPI controller support WS2811; when use DMX decorder, can connect to DMX system
4) Support online control



Application:

To create the flexible LED dispaly, LED curtain.

Indoor & Outdoor decoration, fashion decoration.



Picture show:



non- waterproof type used for indoor, white pcb and black pcb both available.

Waterproof type used for indoor.



SJ-100144-2811 ws2812b pixel strip



SJ-100144-2811 ws2812b pixel strip



Effect: use DMX controller & decoder & SD controller & arduino controller,

each led change color individually and pixel addressable full color.



SJ-100144-2811 ws2812b pixel strip



SJ-100144-2811 ws2812b pixel strip





3 Pin Male and female Connector on each endside, easy for connect.













Install: Every 1m with 2 holders and screw to install, and 3M back adhesive on each strips.





















Package:  4m/ rell 50 rell/ carton size: 46*26*46.5cm total weight :100string /carton
