SJ-10060-2811 ws2812b strip

Specifications

individually control rgb led strip ws2811
1.DC5V14.4W/M
2.WS2811 built into 5050
3.2 years warranty
addressable

SJ-10060-2811 ws2812b strip individually control rgb led strip ws2811



Description:

 Brand new Smart RGB Pixel Strip light---IC built-in ws2811 Digital LED Strip



Each smd 5050 has an IC(ws2811) inserted in,Each LED individually address controlled.

You can design many different  lighting effects or animations you want.

This is the highest resolution one for the moment!

Controller, power supply are available!

Pixel 60pixels/m addressable rgb led pixel strip ws2811, individually control



Feature:

Products Name	WS2811 Led pixel strip
Model NO.	SJ-10060-2811
Power Consumption	14.4W/Meter
Work Voltage	DC5V
IC model	ws2811 built into 5050
LED Qty	60pcs SMD5050RGB
PCB Color	black/white
Dimension	L1000*W12*H3mm
Waterproof Grade	IP65/IP20
Work Temperature	-40-+60°C
Life-span	60,000H
Certificate	CE&RoHS
Warranty	2 years



Control System:

1. Offline control: SJ-T-1000s, SJ-8000C for off-line working, can control max 2048 Pixels, 8192 Pixels.

2. Online control: SJ-T-200K, 300K for on-line working, can control max 4096,8192 pixels.

3. Compatible with Arduino, DMX 512.



CONNECTION:
1) Signal wire: DC+, DAT, GND
2) DC+ and GND connect to power supplier;DAT and GND connect to controller
3) Relative Controller: SPI controller support WS2811; when use DMX decorder, can connect to DMX system
4) Support online control



Application:

To create the flexible LED dispaly, LED curtain.

Indoor & Outdoor decoration, fashion decoration.



Picture:  silicon tube waterproof type used for outdoor







Non-waterproof use for indoor decoration







3 Pin Male and female Connector on each endside, easy for connect.
