LED Dmx Pixel Light 5050 3leds 0.72w 2 Years Warranty Dc12v

LED Dmx Pixel Light 5050 3leds 0.72w 2 Years Warranty Dc12v photo-1
LED Dmx Pixel Light 5050 3leds 0.72w 2 Years Warranty Dc12v photo-2
LED Dmx Pixel Light 5050 3leds 0.72w 2 Years Warranty Dc12v photo-3
US$ 0.5 - 0.9 MOQ: 50 Pieces
Key Specifications
Get Latest Price
LED Light Source:
epistar smd5050 led
Input Voltage(V):
12V
Lamp Power:
0.72
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen yantian
Delivery Detail:
Delivery time depends on order quantity.
LED Light Source epistar smd5050 led
Input Voltage(V) 12V
Lamp Power 0.72
Color Temperature(CCT) Other, iPixel
Working Temperature(℃) -30, 50
Working Lifetime(Hour) 50000
Lamp Body Material Copper
IP Rating IP66
Certification CE
Emitting Color Changeable
Place of Origin Guangdong, China
Brand Name SJ / iPixel
Model Number SJ-219

 LED dmx pixel light 5050 3leds 0.72w 2 years warranty dc12v



description

RGB led pixel round module lights - 3 pcs SMD 5050 RGB 26mm pixel light

RGB Pixels are digitally-controllable lights you can set to any color, or animate

 Each RGB LED and controller chip is molded into a 'dot' of silicone.

The dots are waterproof and rugged.

There are four flanges molded in so that you can 'push' them

into a 26mm drill hole in any material up to 1.5mm/0.06" thick

They're typically used to make outdoor signs. Compared to our other  LED dots

The pixels are connected by a 3-conductor cable. Blue is +12VYellow is GroundGreen is Data

Data is shifted down from one pixel to the next so that you can easily

connect to  the strand or attach more onto the end.



feature:

I   SD controller
l   Programable by Software
l   Individually Control
l   Conformal Coating,PVC glue protection
l   IP66, Water-proof protection
l   Easy installation (punching 26mm hole on metal panel)

l   26mm ucs1903 led rgb pixel module light



 Specifications

Model NO.

SJ-IC219

IC chip

UCS1903

Power Consumption

0.72W

Work Voltage

DC 12V

Beam Angle

120

LED Quantity

3 PCS SMD 5050

Color

Full color (ICRGB)

Dimension

26*33*34mm

Waterproof Grade

IP66

Work Temperature

-40-+60°C

Life-span

50,000H

Certificate

CE&RoHS

Warranty

2 years





Picture:  3pcs smd5050 26mm pixel led waterproof  IP66 used for indoor outdoor,

clear and milky cover.



LED dmx pixel light 5050 3leds 0.72w 2 years warranty dc12vLED dmx pixel light 5050 3leds 0.72w 2 years warranty dc12vLED dmx pixel light 5050 3leds 0.72w 2 years warranty dc12v





Clear and miky cover waterproof 26mm pixel led with 2pcs 3pin connector of each led



Controller:  DMX controller & decoder & SD controller & arduino controller



Effect: every pixel led with ucs1903 control, can change color individually.



Package: 20pcs/string 8cm lead in cable wire, 80pcs/An-ti static bag 640pcs/carton.







LED dmx pixel light 5050 3leds 0.72w 2 years warranty dc12v
