Specifications
3pcs SMD5050 RGB LED26mm RGB led pixel module light
SD controller &Ledwalker
CE & RoHs
2 years
DC 12v addressable 3pcs smd 5050 26mm rgb pixel led led waterproof ip66
description
RGB led pixel round module lights - 3 pcs SMD 5050 RGB 26mm pixel light
RGB Pixels are digitally-controllable lights you can set to any color, or animate
Each RGB LED and controller chip is molded into a 'dot' of silicone.
The dots are waterproof and rugged.
There are four flanges molded in so that you can 'push' them
into a 26mm drill hole in any material up to 1.5mm/0.06" thick
They're typically used to make outdoor signs. Compared to our other LED dots
The pixels are connected by a 3-conductor cable. Blue is +12V, Yellow is Ground, Green is Data
Data is shifted down from one pixel to the next so that you can easily
connect to the strand or attach more onto the end.
feature:
I SD controller
l Programable by Software
l Individually Control
l Conformal Coating,PVC glue protection
l IP66, Water-proof protection
l Easy installation (punching 26mm hole on metal panel)
l 26mm ucs1903 led rgb pixel module light
Specifications
Model NO. |
SJ-IC219 |
IC chip |
UCS1903 |
Power Consumption |
0.72W |
Work Voltage |
DC 12V |
Beam Angle |
≥120 |
LED Quantity |
3 PCS SMD 5050 |
Color |
Full color (ICRGB) |
Dimension |
26*33*34mm |
Waterproof Grade |
IP66 |
Work Temperature |
-40-+60°C |
Life-span |
50,000H |
Certificate |
CE&RoHS |
Warranty |
2 years |
Picture: 3pcs smd5050 26mm pixel led waterproof IP66 used for indoor outdoor,
clear and milky cover.
Clear and miky cover waterproof 26mm pixel led with 2pcs 3pin connector of each led
Controller: DMX controller & decoder & SD controller & arduino controller
Effect: every pixel led with ucs1903 control, can change color individually.
Package: 20pcs/string 8cm lead in cable wire, 80pcs/An-ti static bag 640pcs/carton.
