60mm Turbo Led Pixel Amusement Park Rides Pixels DC24V Waterproof IP68

60mm Turbo Led Pixel Amusement Park Rides Pixels DC24V Waterproof IP68 photo-1
60mm Turbo Led Pixel Amusement Park Rides Pixels DC24V Waterproof IP68 photo-2
60mm Turbo Led Pixel Amusement Park Rides Pixels DC24V Waterproof IP68 photo-3
US$ 1.7 - 1.8 MOQ: 100 Pieces
Key Specifications
Get Latest Price
LED Light Source:
epistar smd5050
Input Voltage(V):
24
Lamp Power:
1.44
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen Yantian
Delivery Detail:
Delivery time depends on order quantity.
LED Light Source epistar smd5050
Input Voltage(V) 24
Lamp Power 1.44
Color Temperature(CCT) Other, pixel
Working Temperature(℃) -30, 50
Working Lifetime(Hour) 50000
Lamp Body Material Copper
IP Rating IP68
Certification CE
Emitting Color Changeable
Place of Origin Guangdong, China
Brand Name SJ / iPIXEL
Model Number SJ-6018S-24V

 60mm turbo led pixel amusement park rides pixels DC24V waterproof IP68



description

RGB led pixel round clear cap lights - 18 pcs SMD 5050 RGB 60mm pixel light

RGB Pixels are digitally-controllable lights you can set to any color, or animate

 Each RGB LED and controller chip is molded into a 'dot' of silicone.

The dots are waterproof and rugged.

There are four flanges molded in so that you can 'push' them

into a 19mm drill hole in any material up to 1.5mm/0.06" thick

They're typically used to make outdoor signs. Compared to our other  LED dots

The pixels are connected by a 3-conductor cable. Blue is +12VYellow is GroundGreen is Data

Data is shifted down from one pixel to the next so that you can easily

connect to  the strand or attach more onto the end.



 Specifications

Model NO.

SJ-6018S-24V

IC chip

UCS2903

Power Consumption

4.32 W

Work Voltage

DC 24V

Beam Angle

360

LED Quantity

18 PCS SMD 5050

Color

Full color (ICRGB)

Dimension

60mm, 19mm install hole

Waterproof Grade

IP66, IP68

Work Temperature

-40-+60°C

Life-span

50,000H

Certificate

CE&RoHS

Warranty

2 years



 Control system:

1.wire signal:  DC+,CLK,GND

2.led controller: t-1000s sd card controller, t-200k,t-8000c, etc.

3.can work with DMX,Artnet,Arduino



Application:

1. Channel Letters Back lighting;

2. Backlight of signage, channel letter, signs, light box

3. Advertisement signs Back lighting

4. Advertisement Light Boxes Back lighting

5. Decoration lights for bar, pub, club, disco



Picture details for 60mm pixel led:



18pcs high light smd5050 in 60mm white/clear cover waterproof ip66 IP68 both available



60mm turbo led pixel amusement park rides pixels DC24V waterproof IP6860mm turbo led pixel amusement park rides pixels DC24V waterproof IP6860mm turbo led pixel amusement park rides pixels DC24V waterproof IP6860mm turbo led pixel amusement park rides pixels DC24V waterproof IP6860mm turbo led pixel amusement park rides pixels DC24V waterproof IP68



Controller and effect:  DMX controller & decoder & SD controller & arduino controller,

 every pixel led with ucs1903 control, can change color individually.



60mm turbo led pixel amusement park rides pixels DC24V waterproof IP68



Other pixels: 26mm, 35mm, 45mm, 60mm , all provide in IP66 and IP68 version.
