Product Details
Place of Origin: | Shanghai, China | Brand Name: | digital time relay | Model Number: | DI-J11 |
Theory: | Time Relay | Usage: | Auto | Size: | Subminiature |
Protect Feature: | Sealed | Contact Load: | High Power |
Product Description
digital time relay
Ⅰ. Description digital time relay
Micro-processing chip as the core chip;
8 modes of operation for easy use;
Wide voltage range: AC/DC24~240V;
Wide working range: 0.6s~100h, multi-way delay, time adjustable;
Stable, reliable and strong anti-interference
Standards: GB14048.5-2001; CCC & CE approves
Ⅱ. Features digital time relay
1) Preset delay time among the timing range.
2) ON/OFF per day
3) 1NC load and 1NO load
4) By auto control
Ⅲ. Specifications digital time relay
Operating Voltage: | AC/DC24~240V digital time relay |
Mechanical life: | more than 107 circles |
Power consumption: | AC max 0.6VA, DC max 0.6W |
Electrical Endurance: | more than 105 circles |
Delay timing range: | 0.6 s ~100h |
Repeated error: | less than +/-0.5% |
Installation: | guide rail |
Set error: | +/5%FS |
Temperature: | -10℃~+55℃ (no frozen) |
Output: | 1 group 3A 250V AC |
Operating humidity: | 45~85%RH |
Weight: | about 80g |
digital time relay
1. Reply your enquiry in 24 working hours.
2. Experienced staffs answer all your questions in professional and fluent English.
3. Customized design is available. OEM & ODM are welcome.
4. Exclusive and unique solution can be provided to our customer by our well-trained and professional engineers and staffs.
5. Special discount and protection of sales area provided to your distributor.
digital time relay
certificates:
Q 1. what's the delivery time?
Q 2. tell me the standard of package?
A. Standard export packing is nutural carton box.
Q 3.Can you accept to use our logo?
A.If you have good quantity,it absolute no problem to do OEM.
Q 4.We want to know monthly capacity.
A. 200000pcs/month.
