Description:
Pin type bead mill for carbon black
Model:
ESSF-Type Bead Mill
Characteristics:
New design of pin-type grinding components, with high grinding efficiency and high output, but low energy consumption.
With smaller length/diameter ratio and higher energy density.
Using large flux static centrifugal separation screen, with larger discharging area, grinding medium without contact with the screen, no abrasion, thus with longer service life.
Grinding barrel and grinding rotor adopt forced cooling system, with lower discharging temperature and no influence of sensitive materials.
Adopting high quality wear-resisting alloy steel, reduce pollution to materials in the processing of grinding .different materials are optional as per different products, such as stainless steel, high polymer materials, ceramics, etc.
Application area:
Digital printing ink, solvent ink, water-based ink, automobile paint, industrial coating, pigments, color paste, and nanometer materials.
Technical Data:
|
Parameter
Type |
Total Volume (L) |
Working Volume (L) |
Power (KW) |
Batch (L) |
Cooling Water (L/h) |
Max line velocity (m/s) |
ESSF1 |
1.8 |
1 |
2.2 |
2~10 |
100 |
12 |
ESSF2 |
3.6 |
2 |
3 |
3~20 |
100 |
12 |
ESSF10 |
17 |
10 |
18.5 |
300~1000 |
1500 |
14 |
ESSF20 |
35 |
18 |
30 |
500~1500 |
2000 |
14 |
ESSF30 |
44 |
25 |
45 |
500~2000 |
2000 |
14 |
ESSF60 |
110 |
60 |
75 |
1000~3000 |
2500 |
15 |
ESSF150 |
290 |
150 |
160 |
2000~5000 |
4000 |
16 |
