High conversion rate poly solar panel solar absorber plate pv solar module 270watt
Characteristic:
1.High-efficiency silicon battery guarantee steady and persistent output power.
2.Strict quality test conform to international standard.
3.Transparent toughened glass and anticorrosive EVA protect the battery panels effectively.
4.The power output performance are stable
Solar panels / solar modules : monocrystalline solar panels / crystalline solar pales for on-grid and off-grid residential and commercial systems.
Applications:
Solar garden light
Mini-household lighting system
Solar street lamp
Solar outdoor advertising
Suit for various kinds of mini watt appliances:emergency light,advertising lamp,traffic light,house light,electric fan,Solar water pump,solar mini-system.
Feature and advantage:
1.High conversion rate and high efficiency output.
2.Excellent effect of weak light.
3.Choose high transparency and superior toughened glass.
4.The beautiful easy installation module is made by special technology for firm enough to resistance to the wind and snow.
5.Unique technology avoid the water accumulation to freeze to deform frame.
5 years material and workmanship guarantee
95% power output guarantee for 5 years
90% power output guarantee for 10 years
80% power output guarantee for 25 years
High conversion efficiency with high reliability
Low mismatch of cell performance during encapsulation
Excellent performance under low lighting
Low hot spot effect
Low degradation under light exposure
| Mono Solar panel Model |
Maximum power Voltage | power Current | Open Circuit Voltage | Short Circuit Current | Module Dimension (mm) | |
| Pm(W) | Vm(V) | Im(A) | Voc(V) | Isc(A) | ||
| BP-M3W | 3 | 9 | 0.34 | 9.5.62 | 0.34 | 180×180×15 |
| BP-M5W | 5 | 9 | 0.56 | 9.5.62 | 0.61 | 270×255×18 |
| BP-M10W | 10 | 18 | 0.56 | 21.24 | 0.62 | 340×285×18 |
| BP-M20W | 20 | 18 | 1.11 | 21.24 | 1.22 | 490×370×25 |
| BP-M30W | 30 | 18 | 1.66 | 21.24 | 1.83 | 540×420×25 |
| BP-M40W | 40 | 18 | 2.22 | 21.24 | 2.44 | 640×540×30 |
| BP-M50W | 50 | 18 | 2.78 | 21.24 | 3.05 | 640×540×30 |
| BP-M60W | 60 | 18 | 3.33 | 21.24 | 3.66 | 805×535×30 |
| BP-M80W | 80 | 18 | 4.45 | 21.24 | 4.88 | 1190×540×35 |
| BP-M90W | 90 | 18 | 5 | 21.24 | 5.5 | 1190×540×35 |
| BP-M100W | 100 | 18 | 5.56 | 21.24 | 6.1 | 1190×540×35 |
| BP-M120W | 120 | 18 | 6.67 | 21.24 | 7.33 | 1190×540×35 |
| BP-M130W | 130 | 18 | 7.23 | 21.24 | 7.9 | 1480×680×35 |
| BP-M150W | 150 | 36 | 4.17 | 42.48 | 4.58 | 1480×680×35 |
| BP-M160W | 160 | 36 | 4.59 | 42.48 | 5.04 | 1580×805×35 |
| BP-M170W | 170 | 36 | 4.73 | 42.48 | 5.21 | 1580×805×35 |
| BP-M180W | 180 | 36 | 5 | 42.48 | 5.5 | 1580×805×35 |
| BP-M200W | 200 | 36 | 5.84 | 42.48 | 6.42 | 1580×805×35 |
| BP-M240W | 240 | 36 | 6.66 | 42.48 | 7.33 | 1640×990×35 |
| BP-M250W | 250 | 36 | 6.69 | 42.48 | 7.63 | 1640×990×35 |
| BP-M260W | 260 | 36 | 7.22 | 42.48 | 7.94 | 1640×990×35 |
| BP-M270W | 270 | 36 | 7.5 | 42.48 | 8.25 | 1950×990×50 |
| BP-M280W | 280 | 36 | 7.77 | 42.48 | 8.55 | 1950×990×50 |
| BP-M290W | 290 | 36 | 8.05 | 42.48 | 8.86 | 1950×990×50 |
| BP-M300W | 300 | 36 | 8.3 | 42.48 | 9.16 | 1950×990×50 |
| Poly Solar | Pm(W) | Maximum power Voltage Vm(V) | Maximum power Current Im(A) | Open Circuit Voltage Vm(V) | Short Circuit Current Isc(A) | Module Dimension |
| Panel Model | L*W*H (mm) | |||||
| BP-P3W | 3 | 9 | 0.34 | 9.5.62 | 0.34 | 180×180×15 |
| BP-P5W | 5 | 9 | 0.56 | 9.5.62 | 0.61 | 270×255×18 |
| BP-P10W | 10 | 18 | 0.56 | 21.24 | 0.62 | 340×285×18 |
| BP-P20W | 20 | 18 | 1.11 | 21.24 | 1.22 | 490×370×25 |
| BP-P35W | 35 | 18 | 1.95 | 21.24 | 2.15 | 540×420×25 |
| BP-P40W | 40 | 18 | 2.22 | 21.24 | 2.44 | 640×540×30 |
| BP-P50W | 50 | 18 | 2.78 | 21.24 | 3.05 | 640×540×30 |
| BP-P560W | 60 | 18 | 3.33 | 21.24 | 3.66 | 805×535×30 |
| BP-P80W | 80 | 18 | 4.45 | 21.24 | 4.88 | 1190×540×35 |
| BP-P85W | 85 | 18 | 4.72 | 21.24 | 5.19 | 1190×540×35 |
| BP-P100W | 100 | 18 | 5.56 | 21.24 | 6.1 | 1190×680×35 |
| BP-P120W | 120 | 18 | 6.67 | 21.24 | 7.33 | 1190×680×35 |
| BP-P130W | 130 | 18 | 7.9.523 | 21.24 | 7.9 | 1480×680×35 |
| BP-P150W | 150 | 36 | 4.17 | 42.48 | 4.58 | 1480×680×35 |
| BP-P170W | 170 | 36 | 4.73 | 42.48 | 5.21 | 1350×1000×35 |
| BP-P180W | 180 | 36 | 5 | 42.48 | 5.5 | 1350×1000×35 |
| BP-P200W | 200 | 36 | 5.84 | 42.48 | 6.42 | 1350×1000×35 |
| BP-P230W | 230 | 36 | 6.39 | 42.48 | 7.02 | 1640×990×35 |
| BP-P270W | 270 | 36 | 7.5 | 42.48 | 8.25 | 1950×990×50 |
| BP-P280W | 280 | 36 | 7.77 | 42.48 | 8.55 | 1950×990×50 |
| BP-P290W | 290 | 36 | 8.05 | 42.48 | 8.86 | 1950×990×50 |
| BP-P300W | 300 | 36 | 8.3 | 42.48 | 9.16 | 1950×990×50 |
Payment & Shipping & Sample
1. Payment: T/T (Telegraphic transfer), and Western Union
2. Delivery time: 7 workdays for sample; 20-25 workdays for mass order
3. Shipping: DHL, FEDEX, UPS, EMS, Airway and By Sea
**Welcome Sample Order to test quality firstly**
Warranty :
Our product warranty is valid for 5 years after delivery. We undertake to repair any malfunctioned units due to defective components of inadequate workmanship ,but specially expecting any defects resulting from normal wear and tear of improper use of the products.
Samples and OEM
Samples are Available for Testing and Market Test. OEM is welcomed for us.
