Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Products Status:
Stock
Computer Connections:
16 Ports
Monitor Connections:
1 Ports
Payment & Shipping
Payment Methods:
Port of Shipment:
FOB SHENZHEN
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Products Status
Stock
Computer Connections
16 Ports
Monitor Connections
1 Ports
Interface Type
PS/2
Resolution
1024 x 768
Brand Name
EDNSE
Model Number
ED1516H
Place of Origin
Guangdong, China
Specifications
EDNSE KVM ED1516H1.15"TFT Rackmount Monitor LCD KVM
2.Dual interface PS/2,USB control computer
| KVM-ED1516H Series |
| 15"TFT Rackmount Monitor LCD KVM |
| Dual interface PS/2,USB control computer |
| Support DDC2B |
| Password security protection |
| Withdrawing installation design |
·LCD display/Touchpad mouse/104 Keyboard with Digital Zone/E-Switch.
·Excellent video effects, the best resolution is up to1024*768 60HZ.
·Support DDC2B.can detect the screen model without switching the computer.
·Dual interface PS / 2 , USB keyboard and mouse are connected to control computer.
·Withdrawing installation design, the length can be adjusted to fit the rack space.
·Humanized design,can be installed and removed by only one person which improves the efficiency of the administrator.
·To switch the host computer though the hotkey or OSD menu, it can manage up to 512 computers.
·Password security protection, only authorized users can view and manage on-line computer.
·Support a variety of brand industrial computer and the server,such as Siwei, EVOC, Lenovo, IBM, DELL, HP, SUN, etc.
·support various operating systems: Microsoft, Linux, Unix, etc.
·Excellent video effects, the best resolution is up to1024*768 60HZ.
·Support DDC2B.can detect the screen model without switching the computer.
·Dual interface PS / 2 , USB keyboard and mouse are connected to control computer.
·Withdrawing installation design, the length can be adjusted to fit the rack space.
·Humanized design,can be installed and removed by only one person which improves the efficiency of the administrator.
·To switch the host computer though the hotkey or OSD menu, it can manage up to 512 computers.
·Password security protection, only authorized users can view and manage on-line computer.
·Support a variety of brand industrial computer and the server,such as Siwei, EVOC, Lenovo, IBM, DELL, HP, SUN, etc.
·support various operating systems: Microsoft, Linux, Unix, etc.
Specifications:
Model: | KVM-1501H KVM-1504H KVM-1508H KVM-1516H |
Computer Connections: | Direct 1, Max:4 Direct 4, Max:128 Direct 8, Max: 256 Direct 16, Max: 512 |
Cable port: | D-SUB15 (LCD, PS11/USB keyboard, mouse),OSD switch Support |
Switch mode: | Hotkey, OSD menu |
Switch Scan Time: | 1-255 second (OSD adjustable) |
LCD Display: | 15" TFT LCD Resolution : 1024*768 Brightness:250nits Contrast: 400:1 |
Keyboard/Mouse: | 104 Mechanical mute Keyboard Touchpad |
Input: | AC100-240V 47-63Hz, 30W |
Cabinet Material: | high-strength and Anti-corrosive steel plate |
Color : | Insulated black paint (other colors optional) |
Dimension ( L x W x H ): | 533.6mmx480mmx44mm |
Weight: | 19.7-24.2Kg |
For cabinet: | 800-1040mm |
Storage temperature: | -30°C~70°C |
work temperature: | -10°C~60°C |
Humidity: | 0%-80%RH |
Certificate: | CCC, FCC, CE |
Whole rendering
Rear view
