Water Bottling Machine
- 1 Set / Sets per Month
- Shanghai Port
- T/T
You May Like
Product Details
| Condition | New | Application | Beverage | |
| Packaging Type | Bottles | Packaging Material | Other, wooden crate | |
| Automatic Grade | Automatic | Driven Type | Electric | |
| Power | 1.37-9.87kw | Place of Origin | Jiangsu, China | |
| Brand Name | HUANYU | Model Number | CGF |
Product Description
Specifications
Water Bottling Machine:Bottling speed:2000-36000bph
All stainless steel make
To bottle water into bottle automatically
CE
Water Bottling Machine:
Bottling speed:2000-36000bph
All stainless steel make
To bottle water into bottle automatically
CE
Water Bottling machine:
Usage: The Water Bottling Machine is mainly used for washing, filling sealing non carbon dioxide drink such as mineral water, pure water, non-gas wine drink and so on. Characteristics: Filling Machine 3-In-1 for Non-Carbonated Drink adopts hanging type conveying-bottle structure to make changing bottle model more convenient, faster and more east. The main machine adopts advanced PLC control technology. The key electric elements adopt international famous products. For the further details, you can visit our websites.
| Model: | CGF16/12/6 | CGF16/16/6 | CGF18/18/6 | CGF24/24/8 | CGF32/32/10 |
| Production(500/m/bottle/h): | 3000 | 5000 | 8000 | 10000 | 12000-14000 |
| washing filling and capping heads | 16 12 6 | 16 16 6 | 18 18 6 | 24 24 8 | |
| Bottle size | Circular or square bottleBottle diameter(mm): Φ50-φ90 Bottle height(mm): 150-310 | ||||
| Compressed air pressure(MPa): | 0.3-0.7 | ||||
| Washing medium: | Aseptic water Washing | ||||
| waters pressure(MPa): | 0.25 | ||||
| Total output (KW): | 3.13 | 3.84 | 3.84 | 4.1 | 5.6 |
| Oerall dimensions(mm): | 2500x1500x2500 | 2500x1800x2500 | 3200x2200x2800 | 3400x2600x2800 | 3600x2800x3000 |
| Weight (kg): | 2500 | 3000 | 3500 | 4500 | 5000 |
Automatic Washing machine
automatic filling machine
