Washing Filling and Capping Machine 4-In-1 Unit for Water
US$ 6,000 - 100,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Application:
Other, water
Driven Type:
Electric
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai Port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
3 In 1 Filling MachineUS$ 20,000 - 100,000MOQ: 1 Set -
Water Linear Packing MachineUS$ 10,000 - 100,000MOQ: 1 Set
-
Water Washing/filling/capping Machine MonoblockUS$ 10,000 - 80,000MOQ: 1 Set
-
Mineral Water/ Pure Water Filling MachineUS$ 5,000 - 100,000MOQ: 1 Set
-
Linear Mineral Water Washing/filling/capping MachineUS$ 10,000 - 100,000MOQ: 1 Set
Condition
New
Application
Other, water
Driven Type
Electric
Automatic Grade
Automatic
Power
1.5-11kw
Packaging Type
Bottles
Packaging Material
Plastic
Place of Origin
Jiangsu, China
Brand Name
HUANYU
Model Number
CGF18-18-6
Specifications
Washing Filling and Capping Machine for WaterSpeed: 2000-36000bph
Filling valve precision is highest
Roller bearing has oil
Washing Filling and Capping Machine for Water
Speed: 2000-36000bph
Filling valve precision is highest
Roller bearing has oil
Usage: The line is mainly used for washing, filling sealing non carbon dioxide drink such as mineral water, pure water, non-gas wine drink and so on. Characteristics: It adopts hanging type conveying-bottle structure to make changing bottle model more convenient, faster and more east. The main machine adopts advanced PLC control technology. The key electric elements adopt international famous products. For the further details, you can visit our websites.
| Model: |
CGF16/12/6 | CGF16/16/6 | CGF18/18/6 | CGF24/24/8 | CGF32/32/10 |
| Production(500/m/bottle/h): | 3000 | 5000 | 8000 | 10000 | 12000-14000 |
| washing filling and capping heads | 16 12 6 | 16 16 6 | 18 18 6 | 24 24 8 | |
| Bottle size | Circular or square bottleBottle diameter(mm): Φ50-φ90 Bottle height(mm): 150-310 | ||||
| Compressed air pressure(MPa): | 0.3-0.7 | ||||
| Washing medium: | Aseptic water Washing | ||||
| waters pressure(MPa): | 0.25 | ||||
| Total output (KW): | 3.13 | 3.84 | 3.84 | 4.1 | 5.6 |
| Oerall dimensions(mm): | 2500x1500x2500 | 2500x1800x2500 | 3200x2200x2800 | 3400x2600x2800 | 3600x2800x3000 |
| Weight (kg): | 2500 | 3000 | 3500 | 4500 | 5000 |
Washing, filling and capping machine monoblock
Washing, washing, filling and capping machine 4-in-1 machine monoblock
