Help Center24-Port and 48-Port Keystone Jack 110 and LSA+ IDC 6-in-1 Modular Patch Panels
Related Products
-
24 Port Staggered UTP Blank Patch Panel for RJ45 Cat6A Keystone JackNegotiableMOQ: 500 Pieces -
24Port Cat6 6-in-1 UTP Modular Patch PanelNegotiableMOQ: 500 Pieces
-
1U 48 Port UTP Snap-In Type Empty Patch PanelNegotiableMOQ: 500 Pieces
-
1U 24 Port Angle Discrete UTP Blank Patch PanelNegotiableMOQ: 500 Pieces
-
1U 24Port Cat6 Front Access Snap-In Type Empty Patch PanelNegotiableMOQ: 500 Pieces
Patch Panels (BP) REGULAR TYPE
Modular Series
The modular patch panels utilize quad frame modules offered with 8-contact inserts wired to IDC (Insulation Displacement Connectors). It meets or exceeds all requirements set forth in American National Standards Institute / Telecommunications Industry Association / Electronic Industries Alliance standard when using UTP cabling with frequencies up to 250MHz.
§ APPLICATION
The patch panels are most commonly used at the cross-connect area for switches to the distribution side of the network, and can be mounted on 19" EIA racks or cabinets.
§ FEATURE
- Meet & Exceed TIA/EIA-568-B.2 Category 5e connecting hardware specification. Certified by UL.
- Using snap-on type Frame, no any screws on front side of panel.
- 110E & 110K type IDC termination. It allows connection with 22-26 AWG wires.
- Colored Fame to avoid confusion each time you need to re-assign your network wiring.
- Special color code design for easy installation.
- RoHS Compliant.
| Ordering Information | |||
| Part No. | Description | Height |
|
|
HC-BP24-S86-C6ABL |
24-Port Cat.6 Unshielded Patch Panel, 6-in-1, 110 IDC. | IU | |
|
HC-BP48-S86-C6ABL
|
48-Port Cat.6 Unshielded Patch Panel, 6-in-1, 110 IDC. | 2U | |
TWISTED-PAIR MULTIMEDIA OPTICAL FIBER OEM/ODM
OEM & ODM: Why HCI?
One of Taiwan’s leading supplier oftelecommunications structured cabling system.
Provide total solution, from design to production with fast turn around time and the best price.
Founded in 1975 and over 25 years experience in OEM/ODM projects.
Your reliable global partner!
