DY-MSAL Medium-size Driving Type Airless Road Marking MachineDimension: 3700*1800*2450mm
DY-MSAL Medium-size Driving Type Airless Road Marking Machine
DY-MSAL Medium-size Driving Type Airless Road Marking Machine is the high-tech product. It has the original imported variable speed transmission system with automatic brake device. And it is controlled by micro-electric system, to improve the marking speed and reducing labor intensity.
Main feature for DY-MSAL Medium-size Driving Type Airless Road Marking Machine
1.Micro-electric control system, which can freely set the line type of single actual line,double actual line and other broken line. According to the needs of customer it can update the other function to make the road marking construction easy and convenient.
2.Equipped with three new type pneumatic spray guns and one hand spray gun with lengthening pipes and install with hard side columnar reverse wastewater nozzle (30/20). It can make the on-spot discharging easy and convenient and the non-arc nozzle ensures the base line collimated. According to the needs of project, three spray guns can start at the same time.
3.Automatic definite quantity spraying can work synchronously with the paint spraying system, which ensures the dispensing evener and more economical.
Technical datafor DY-MSAL Medium-size Driving Type Airless Road Marking Machine
No. |
Item |
Technical Data |
1 |
Engine |
25HP water-cooled electrical starting diesel |
2 |
Driving system |
Oil pressurized continuously variable speed |
3 |
Driving speed |
Forward: 0-22km/h, back off: 0-12km/h, Max climbing capacity: 15° |
4 |
Spray width |
100-450mm |
5 |
Glass bead spraying system |
Automatic definite quantity spraying can work synchronously with the paint spraying system |
6 |
Spray gun |
Three new type pneumatic spray guns and one hand spray gun with lengthening pipes |
7 |
Control system |
Micro-electric control system |
8 |
Paint tank |
Double tank, 200kg per tank |
9 |
Dimension |
3700*1800*2450mm |
10 |
Weight |
782kg |
Note:
Option for portable hand-push road marking machine to mark special marking, such as pedestrian, parking and lane marking
Picture for DY-MSAL Medium-size Driving type Airless Road Marking Machine
