High Performance Ctp Computer To Plate For Various Purpose
China manufacturer factory price Positive Ctp Computer To Plate
Positive Computer to Conventional Plate
Ctp Computer To Plate
Features Of Ctp Computer To Plate :
1.High quality aluminium substrate
2.Special coating to give excellent inaging quality
3.High Resolution.
4.High Pressrun
5. A wide latitude in operation condition
6. It it suirtable for superb color business printing
Technical parameters of Ctp Computer To Plate :
Name : offset plates CTcP,UV-CTP plate:
Application: Newspaper printing, Commercial printing etc...
Alloy and temper : 1060/H18
Gauge : 0.14mm -0.30mm
Spectral Sensitivity : 400-410nm
Sensitivity : 70-90 mj/cm²
Developing Temperature : 25±2℃
Developing Time : 20±5s
Safelights: safe yellow lights
Dot reproduction:2-98%@ 175 lpi
Press suns of 50000 (un-baked), 100000( baked)
Shelf Life : 18 months shelf life from date of production when stored in a cool,dry and lucifugal area in original packing.
Storage conditions: temperature 5-30°C, RH:≤65°C, Stacking height :≤1.2m
Suitable for 405nm CTCP printing;developing system .
Technical parameters for Ctp Computer To Plate :
UV CTP Technical specifications | |
Plate Type |
Positive offset plate for Ctp Computer To Plate |
Application |
All kinds of CTCP machine |
Substrat |
Electrochemically grained and anodized aluminum |
Thickness |
0.15mm-0.30mm |
Maximum short grain width |
1500mm |
Spectral sensitivity |
350-420nm UV light |
Plate setter compatibility |
Luscher XPose! UV, Basysprint UV-Setter, Cron UVP etc. |
Safelights |
UV filtered or Yellow |
Sensitivity |
60-70mj/cm2 |
Development |
Conductivity: min 55ms, max 65ms |
Developer |
Common positive offset plate developer |
Dot reproduction |
1%--99% 200lines/inch |
Final image colour |
Green |
Shelf life |
12 months when stored in a light-free area away from excessive cold, heat and high humidity |
Run length |
0.30mm above 100, 000 (Actual run length may vary according to press, ink and stock conditions. |
Technical parameters for Ctp Computer To Plate
Style |
Positive CTcP Plate |
|
Application Type |
Newspaper printing , Commercial printing, etc |
|
Compatibility |
Basys, Luscher, CRON, etc |
|
Plate Thickness |
0.15mm-0.30mm |
|
Spectral Sensitivity |
405-410nm |
|
Developing Temperature |
23±2°C |
|
Developing Time |
20±5s |
|
Developing ratio |
1:4-1:5 (use after being diluted) |
|
Safelight |
Yellow light |
|
Shelf life |
18 months |
|
Storage Conditions |
The recommended storage conditions are 10-25°C,with 40%--70%humidity. Away from sunlight radiation &direct sunlight, Anti-humidity, Anti-acid &alkali. |
|
Packing and Delivering Of Ctp Computer To Plate
We usually use container to deliver our products. And first, we will packaged our products by plastic to prevent being mositured, then we will use frame to fix this plate. no matter what, please do not worry about delivering, because we have been this field for many years, we will try our best to offer you the greatest goods.
Before Service: we will try our best with professional advice to gve you the best reasonable product
During Service:will make sure that these products will be deiliverd to customer's port.
After Service:we like to solve problems with prossional knowledge.
HAOMEI is a professional manufacturer of Ctp Computer To Plate , UV-CTP(CTcP) Plates and Thermal CTP Plates in China. HAOMEI brand printing plates are popular in mainland and oversea, widly used in prining market like newspaper, commercial print, etc.
We can also offer these following products :
1.Why did you choose our company?
Because our company has been in this field for almost 15years with customers from all over the world.
2.What did we mainly focus on?
we are manufacturers for Ctp Computer To Plate , aluminum sheet , aluminum circle, aluminum foil roll, aluminum strip and so on aluminum products.
