Specifications
Products : led rgb rainnyproof controller
Type : led controller
I. Technical Parameter:
Working temperature | -20-60 °C |
Supply voltage | DC5V, 12V, 24V |
Size | L168*W130*H60mm |
Net weight | 190g |
Output | Three CMOS drain- open output |
Output current | <4A(each channel) |
Output power | 5V:<60W,12V:<144W,24V:<288W |
Connecting Mode | Common anode/ cathode |
II. Control method
1.Connect the load wire at first, following by the power wire; Please ensure short circuit can not occur between connecting wire before you turn on the power;
2. Standard color changes as follows:
Brightness +( 8 in all ) | Brightness-(8 in all ) | Off | On |
Static red | Static green | Static blue | Static white |
Static Yellow | Static cyan | Static purple | 3 base color jumpy |
Increase red | Increase green | Increase blue | 7 colors jumpy |
Decrease red | Decrease green | Decrease blue | 3 base colors fade change |
DIY1 | DIY 2 | DIY 3 | 7 colors fade change |
DIY4 | DIY5 | DIY jumpy change | Spark |
III.Panel specification and connecting drawing as follows:
Packing&payment& Delivery
1pc in white box, White box: L137*W78*H57mm
100pcs/carton, carton size:L23''*W15.8''*H11.8''/2.48'
Payment: T/T
Packaging Detail: | White box |
Delivery Detail: | 5 days after confirmed orders and received your deposit |
Our Services:
1. Your inquiry related to our products or prices will be replied in 24 hours
2. Well-trained and experienced staffs to answer all your inquiry in fluent English
3. OEM and ODM, any your customized Lighting & Controller we can help you design put into product
4. Distributorship are offered for your unique design and some our current models
5. Protection of your sales area, ideas of design and all your private information
Picture:
Other design :
