100KVA Silent Diesel Generator Sets RD100-P

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Fujian, China

Model Number:

RP-100P

Output Type:

AC Three Phase

Fujian Robust Power Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Fuzhou

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Fujian, China

Model Number RP-100P

Output Type AC Three Phase

Speed 1500RPM

Frequency 50HZ

Rated Power 80KW

Rated Voltage 230V/400V

Engine:

Model:1104C-44TAG2

Bore x stroke:102 x 120

Cylinder number:6L

Displacement(L):5.9

Induction system:Turbocharged and aftercooled

Prime output:110Kw

Governor type:Electronical Governor

Alternator:

Make:LEROY SOMER

Model:LSA44.2 VS45

STAMFORD & Chinese brushless alternator is optional.

Perkins power water-cooled generator set

ALTERNATOR	Alternator Model	LSA44.2 VS45
	Rated power (Kw/Kva)	80/100
	Voltage (V)	400/230
	Current (A)	144
	Frequency (Hz)	50/60
	Power factor cosφ	0.8(lagging)
	Excitation mode	Brushless self-excitation
	Phase/Connection	3-phase 4-wire Y type connection
	Voltage regulation rated	≤±1%
	Voltage Regulation	Automatic
	Insulation grade	H
ENGINE	Engine model	1104C-44TAG2
	Intaking method	Turbocharged and aftercooled
	Bore x stroke (mm)	102×120
	Displacement (L)	6L
	Compression ratio	16.4:1
	Rated power (Kw)	110
	Lube oil capacity (L)	16
	Fuel consumption rate(g/kW.h)	≤220
	Starting system	24V Electric starter
Dimensions(L×W×H)mm		22357301595
Net Weight (Kg)		1090
