Weifang Durable Silent Mobile Diesel Generator Set RD-100W
US$ 99 - 99,999
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Fujian, China
Brand Name:
Weifang
Model Number:
RD-100W
Payment & Shipping
Payment Methods:
Port of Shipment:
Fuzhou
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Fujian, China
Brand Name
Weifang
Model Number
RD-100W
Output Type
AC Three Phase
Speed
1500RPM
Frequency
50HZ
Rated Power
80KW
Rated Voltage
230V/400V
Specifications
RD-100W diesel generator sets1.Output 50HZ at 1500RPM,3P,400/230V
2.Prime:80Kw / 100Kva
3.Standby:88Kw / 110Kva
Engine:
Model:R6105AZLD
Bore x stroke:105 x 130
Cylinder number:6L
Displacement(L):6.49
Induction system:Turbocharged
Prime output:110Kw
Governor type:Mechanical Governor
Alternator:
Make:Wangwangtong
Model:WTW274C
STAMFORD & Leroy Somer alternator is optional.
Cummins power water-cooled generator set
| ALTERNATOR | Alternator Model | WTW274C |
| Rated power (Kw/Kva) | 80/100 | |
| Voltage (V) | 400/230 | |
| Current (A) | 144 | |
| Frequency (Hz) | 50/60 | |
| Power factor cosφ | 0.8(lagging) | |
| Excitation mode | Brushless self-excitation | |
| Phase/Connection | 3-phase 4-wire Y type connection | |
| Voltage regulation rated | ≤±1% | |
| Voltage Regulation | Automatic | |
| Insulation grade | H | |
| ENGINE | Engine model | R6105AZLD |
| Intaking method | Turbocharged | |
| Bore x stroke (mm) | 105×130 | |
| Displacement (L) | 6L | |
| Compression ratio | 16.4:1 | |
| Rated power (Kw) | 110 | |
| Lube oil capacity (L) | 16 | |
| Fuel consumption rate(g/kW.h) | ≤218 | |
| Starting system | 24V Electric starter | |
| Dimensions(L×W×H)mm | 2800*1100*1600 | |
| Net Weight (Kg) | 1820 | |
