Help CenterSilence Diesel Generator 25KW
Related Products
Model : RPD6700iW
Rated Frequency (HZ): 50/60
Rated Power (kw): 2.8/3
Rated Voltage (v):230/240
Rated Current (A): 12.2/12.5
Phase Number: Single
Power Factor (cos):1
Welding Voltage at zero Load(DC)(V): 60-65
Rated Welding Current DC(A): 160
Welding Voltage (DC)(V):26
Welding Load Continuous Ratio: 60%
Welding Current Adjustment Range (A): 50-180
Electrode (mm): 1.6-4.0
Rated Speed (r/min): 3000/3600
Excitation Mode: Self-excitation and constant voltage
Rectifying Mode: IGBT+three-phase rectifying bridge (PWM)
Insulation Grade: B
Pole Number: 2
Engine Model: RP186FA
Engine Type: Single cylinder, vertical, four-stroke, air-cooled
Displacement (mL): 418
Bore×Stroke(mm):86*72
Compression ratio: 19:01
Rated Power (kw/rpm): 5.7/3000 6.3/3600
Fuel Type: 0(summer)-10(winter)-35(chill cold) diesel
Lube Oil Brand: SAE 10W30 (above cc grade)
Fuel Consumption (g/kw.h):360
Fuel Tank Capacity (L): 16
Continuous Running Time (Hr): 7
Overal Dimension (mm)(L*W*H): 915×547×742
Starting System: electric starter
Noise Level at Rated Load Dba/7m: 70
welding generator
