Diesel Powered Mobile Lighting Tower RPLT4000
Diesel Powered Mobile Lighting Tower RPLT4000
Detail features of RPLT4000
MOBILE LIGHT TOWER SERIES | |
| |
Technical specifications | |
Mast | |
Maximum height of mast |
9m |
Elevation |
Mechanical / Electric |
Raising/lowering mast |
Winch / Button |
Turning angle |
358 degrees |
Stage |
3 |
Lamps | |
Total power of lamps |
4x1,000Watts |
Type of lamp |
Metal halide |
Light capacity |
4x88,000lumen |
Voltages |
120, 220, 230, 240Volts |
Frequency |
50Hz / 60Hz |
Lifetime of lamp |
5,000hours |
Working temperature |
≤85°C |
Protection grade |
IP54 |
Characteristics of generator set | |
Model |
RPD6500I |
Rated power |
4.2kw/50Hz 5.0kw/60Hz |
Engine model |
RP186FA Diesel |
Intake system |
Natural Aspiration |
Engine speed |
50Hz 3000rpm,60Hz 3600rpm |
Type |
Single cylinder, air-cooled |
Starting system |
Electric |
Alternator |
2-pole, brushless |
Fuel tank capacity |
100L |
Fuel consumption at 100% load |
1.85L/H |
Max continuous running time |
60Hours |
Control system |
Digital control panel |
Power Outlets |
2 |
Trailer Type | |
Road trailer with hitch ball | |
Dimension (LXWXH) & Weight | |
Retracted Dimension |
4400x1350x1930 |
Net weight |
680kg |
