10KVA Mobile Lighting Tower
Specifications
Light Tower:1.5KVA-10KVA
2.4 lamps for single phase,3 or 6 lamps for three phase
3.Metal halid lamp
4.6m or 9m mast
|
Hydraulic Elevation Mobile Light Tower
Technical Specifications | |
| Mast | |
| Maximum extention of mast | 8m |
| Elevation | Hydraulic |
| Raising/lowing mast | Button(Hydraulic) |
| Stages | 6 |
| Turning angle | 360 degrees |
| Lamp | |
| Total power of lamps | 4*1000W |
| Type of lamp | Metal halide lamp |
| Light capacity | 4*88000 lumen |
| Voltage | 230V |
| Frequency | 50HZ |
| Lifetime of lamp | 5000 hours |
| Working temperature | ≤85°C |
| Connection protection index | IP54 |
| Trailer Type | |
| Road trailer with hitch ball | |
| Characteristics of the generator | |
| Model | RD-10K |
| Rated power | 50HZ 6.7KW 60HZ 8.4KW |
| Engine model | Kubota D1105-BG Diesel |
| Standby power | 50HZ 6.7KW 60HZ 11.5KW |
| Intake system | Natural Aspiration |
| Type | Vertical 4-cycle water-cooled |
| No. of cylinders | 3 |
| Alternator model | Stamford PI 044F |
| Type | Brushless,self-excitation |
| Voltage regulation | Automatic |
| Alternator prime power(pf:0.8) | 50HZ 6.7KW 60HZ 8.4KW |
| Voltage | 230V |
| Frequency | 50HZ |
| Fuel tank capacity | 100L |
| Prime fuel consumption at 100% load | 2.0L/h |
| Maximum continuous running time | 50 |
| Dimension | |
| Storage | 2650mm*1300mm*2450mm |
