13 m High Mast Generator Movable Lighting Tower

Name: 13 m High Mast Generator Movable Lighting Tower
Brand: ROBUST POWER
SKU: 134530387
Availability: InStock

Fujian Robust Power Co., Ltd.

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Fujian, China

Brand Name:

ROBUST POWER

Model Number:

RPLT9000

Payment & Shipping

Payment Methods:

Port of Shipment:

fuzhou

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Fujian, China

Brand Name ROBUST POWER

Model Number RPLT9000

Specifications

High mast movable lighting tower
1.Mast 9m-13m/Hydraulic/360 degree non continuous
2. Kubota Engine
3.Rate Power:18kw-3kw

High mast generator movable lighting tower

Model number	RPLT-9000
Mast
Maximum extension of mast	9m-13m
Elevation	Hydraulic
Raising/Lowing mast	Button
Stages	6
Turning angle	360 degree non continuous
Lamp
Total power of lamps	4x1000W
Type of lamp	Metal halide lamp
Light capacity	4x110000 lumen
Voltage	120,220,230,240.00
Frequency	50Hz/60Hz
Lifetime of lamo	2000hours
Working temperature	≤85°C
Connection protection index	IP54
Tilted angle of Light bar	5 to 7 acres
Characteristics of the generator
Model	RD-20K
Rated power	50Hz 20KW 60Hz 22KW
Standby power	50Hz 22KW 60Hz 24KW
Engine model	Kubota V2003 Diesel
Engine speed	50Hz 1500rpm 60Hz 1800rpm
Engine type	4 cylinder, in line,water-cooled
Engine Aspiration	Natural
Alternator	4-pole ,Brushless
Fule tank capacity	100L
Prime fuel comsumption at 100% load	4.0L/H
Working hours	25
Emission level	EU Stage III A
Control system	Harsen602 Digital controller
Power Outlets	2
Trailer type
Tow hitch	Ring or ball hitch
Stabilier Supports	4 x Hydraulic
Tire size	52cm
Anti wind capacity	≤10
Brakes	Manual
