High Output Plastic Recycle Machine Factory

Specifications

Plastic Recycle Machine
1.Recycle used tyre,rubber
2.High oil yield
3.Strict quality control
4.ISO9001,ISO14001,CE

High Output Plastic Recycle Machine Factory









Models and parameter:



Model	DY-1	DY-2	DY-3
Capacity per day	6ton	8ton	10ton
Rotate furnace(MM)	2200*4300	2200*4600	2200*5800
structural style	Horizontal rotation	Horizontal rotation	Horizontal rotation
Pressure	ordinary pressure	ordinary pressure	ordinary pressure
Rotation speed	1.2rmp	0.4rmp	0.4rmp
Rotary Motor	4kw	4kw	4kw
type of cooling	water-cooling	water-cooling	water-cooling
Circulating water	1.2t/h	1.5t/h	1.8 t/h
Noise dB(A)	≤62	≤65	≤70



Characteristics and advantages:



1. No special requirement for raw waste tires and plastics.

 2. Operation under atmospheric pressure.

 3. Intellectualized alarm once abnormal pressure.

 4. Automatic decompression and deslagging.

 5. Large diameter of feeding inlet from 1.2m, 1.4m to 1.6m which can be designed based on clients request. Convenient for feeding the big tires and strips of plastic materials with wires.

 6. The mid small feeding inlet, cooperated with the automatic feeder, it can realize the continuous feedings of crushed waste tires and waste papermill materials. Heating, turning while feeding.

 7. Much more energy-saving and environmental. Small area required of reactor and fire channel.

 8. Low cost.



Operation process:





1. No need to clean the water, sand, wire and other impurities from waste rubber and

 waste tyre, they can directly put into the high temperature and normal pressure pyrolyzing reactor for

 catalytic heating to distillate oil vapor.

2. Then the oil gas go through the condenser to get part of liquefying oil and then go into the oil tank.

3. The crude oil after condensation will be heated in fractionation processor

 firstly, and distilled by catalytic reforming process ,then go through condenser to get fractionate fuel oil,

 after precipitation and filtration treatment and adding in additives, the final oil will be qualified fuel oil.

4.With specially analysis and research, we have successfully design a unique process of one pyrolysis,

 twicecatalysis, gas separating pipe and a distillation tower with catalyst specially for gas phase condition

 which can improves the oil quality to a higher level.

5. Then mix the oil with catalyst, after precipitation and filtering, good quality fuel oil and diesel oil are

 obtained, which are close to the national standard.

6.Regarding the dust removal system, more advanced than other traditional treatment way, we arrange

 the FGD fly ash removal device, water dust scrubber device, bagtype strainer and other dust equipment to

 absorb the dust and sulfur dioxide to meet the national discharge standard.





After sales service

1.Installation and training:our company will send one technician for each set of machine for guiding

our installation, testing the machine and training your workers.The installation period shall be 15days



2.Warranty:The warranty period is 1 year.The problem caused by wrong operation of workers shall not be responsible by our company.





Wide range of raw Materials:



1.Waste rubber tire, waste plastic, waste rubber products, etc.

2.Industrial mixed waste plastic, allowing dozens of waste existing at the same time (such as PP, PE, PVC mix together etc).
3.Waste oil:waste diesel, lube oil, engine oil, waste oil residue, mazut, tar oil, wax oil, waste crude oil etc.
4.Waste cable cover.
5.Waste PMMA(methyl methacrylate)rebirth.
6.Drainage oil, acid oil.





Machine model for reffer:





Final output crude oil:
