Help CenterCold&Hot Screw Expeller Machinery With High Output
Related Products
-
Soybean and Peanut Oil Press Machine Saving PowerUS$ 3,200 - 4,000MOQ: 1 Set -
How to Make Sesame Oil/Sesame Oil Pressers/Edible Oil Pressing Production LineUS$ 3,200 - 4,000MOQ: 1 Set
-
Professional Cold Extracted Oil Mill for Olive Fruit and Sesame and Sunflower SeedsUS$ 3,200 - 4,000MOQ: 1 Set
-
Oil Extaction Machine Supplier With a Competitive Price and High Quality/how to Make Edible Cooking OilUS$ 3,200 - 4,000MOQ: 1 Set
-
Sunflower Seeds Oil Presser/oil Presser Factory/oil Presser SupplierUS$ 3,200 - 4,000MOQ: 1 Set
Specifications
screw expeller1.higher output
2..30-80KG/H
3.power saving up to 40%
4.labor saving up tp 60%
Screw expeller
Superiority
1.electronic temperature control and automatic heating
The machine with an automatic temperature control system, pure physical squeezing technology, improved the quality and oil yield efficiency, no pollution to the oil plants and environment.
2.high rate of oil output
The machine has different pitch squeezers composing spiral whole course, making oil convey smoothly and increased squeezer and fuel friction between area and improved the squeezing force, making that oil cells' destruction in the chamber will be more faster, more fully, and oil will be achieved the best pressing particles, shorten the channel for oiling, convenient for oil discharge in quickly and sufficiently.
3.a squeeze net
Adopted multilevel pressing, advancing gradully, reaching a squeeze net
Detailed Photos
Working principle
Dynamic slow down to spindle,installed in the spindle of squeezer with rotation, screw the oil between constantly advancing, because the chamber and the space between the squeezer reduced gradually, and the density of oil increase, so the pressure is gradually increasing.
In the process of pressing, because the machine is selfheating, increased the temperature of principal machine by automatic temperature control device,and thereby reduced labor intensity,the body's wear, saving of labor, saving electricity and time saving.Between the oil particles ,friction in oil plants and parts, produced the quantity of heat.
This constitutes two essential factors in the pressure of pressing and the process of heating, destroyed the histocyte of oil plants, then oil overflowed from the oil line, meal will be pushed out between its head and mouth.
When overflowing oil inflowed through the oil pan into oil filter barrel, the air in the barrel will be pumped out by the vacuum pump.Negative pressure will be formed in the barrel,oil will be pumped into barrel through the filter cloth , and scraps was isolated on the filter cloth, and what we got is the pure oil.
Oil Yield of Raw Materials
raw materials |
oil yield % |
dry bread residual oil rate % |
|
oils |
quality |
|
impurity% |
moisture% |
acid number mgKOH/g |
||||
sesame seed |
≥91 |
≤8.0 |
≤0.2 |
≤0.2 |
≤4.0 |
|
peanut seed |
≥91 |
≤8.0 |
≤0.2 |
≤0.2 |
≤4.0 |
|
rapeseed |
≥80 |
≤8.0 |
≤0.2 |
≤0.2 |
≤4.0 |
|
cottonseed |
≥65 |
≤7.5 |
comply with local standard |
|||
soybean seed |
≥75 |
≤7 |
≤0.2 |
≤0.2 |
≤4.0 |
|
Tips:According to the different areas of the raw material in the oil yield, it has slight changes.
