Specifications
oil mill1.all-in-one
2.handling capacity for 160-210kg/h
3.with vacuum filter
Oil mill
Superiority
1.electronic temperature control and automatic heating
The machine with an automatic temperature control system, pure physical squeezing technology, improved the quality and oil yield efficiency, no pollution to the oil plants and environment.
2.a squeeze net
Adopted multilevel pressing, advancing gradully, reaching a squeeze net
Detailed Photos
Working principle
Dynamic slow down to spindle,installed in the spindle of squeezer with rotation, screw the oil between constantly advancing, because the chamber and the space between the squeezer reduced gradually, and the density of oil increase, so the pressure is gradually increasing.
In the process of pressing, because the machine is selfheating, increased the temperature of principal machine by automatic temperature control device,and thereby reduced labor intensity,the body's wear, saving of labor, saving electricity and time saving.Between the oil particles ,friction in oil plants and parts, produced the quantity of heat.
This constitutes two essential factors in the pressure of pressing and the process of heating, destroyed the histocyte of oil plants, then oil overflowed from the oil line, meal will be pushed out between its head and mouth.
When overflowing oil inflowed through the oil pan into oil filter barrel, the air in the barrel will be pumped out by the vacuum pump.Negative pressure will be formed in the barrel,oil will be pumped into barrel through the filter cloth , and scraps was isolated on the filter cloth, and what we got is the pure oil.
Oil Yield of Raw Materials
raw materials |
oil yield % |
dry bread residual oil rate % |
|
oils |
quality |
|
impurity% |
moisture% |
acid number mgKOH/g |
||||
sesame seed |
≥91 |
≤8.0 |
≤0.2 |
≤0.2 |
≤4.0 |
|
peanut seed |
≥91 |
≤8.0 |
≤0.2 |
≤0.2 |
≤4.0 |
|
rapeseed |
≥80 |
≤8.0 |
≤0.2 |
≤0.2 |
≤4.0 |
|
cottonseed |
≥65 |
≤7.5 |
comply with local standard |
|||
soybean seed |
≥75 |
≤7 |
≤0.2 |
≤0.2 |
≤4.0 |
|
Tips:According to the different areas of the raw material in the oil yield, it has slight changes.
