Specifications
Rotary Dryer:1. High capacity, good quality
2. Perfect output
3. Easy operation and maintainence
4. Low energy consumption
HIGH CAPACITY SAWDUST ROTARY DRYER
Rotary Dryer is used for drying materials with moisture or granularity in hte industries of mineral dressing, building material and metallurgy. In addition, materials suitable for the machine are various, such as: limestone slag, coal powder, slag and clay stone and so on.
Operation principle:
This dryer mainly consist of rotary body, raw material feeding plate, driving and supporting device, etc. Operating process:
1. The raw material plate which is arranged reasonably with changeable angles in order, throws moisture materials into rotary cylinder.
2. Then water will be separated from the materials by hotair-flow and changed intoo vapour to be discharged into the atmosphere. Then the materiasl would be dryer.
Advantages:
1. High capacity, good quality
2. Perfect output
3. Easy operation and maintainence
4. Low energy consumption
Technique parameter:
Model |
Diameter (mm) |
Length (m) |
Inclination |
Cylinder speed (r/min) |
Weight (ton) |
Power (kw) |
Volume(m3) |
DY 0.6×8 |
600 |
8 |
3-5 |
8 |
5.1 |
4 |
2.26 |
DY 0.8×10 |
800 |
10 |
3-5 |
7.2 |
6.9 |
4 |
5.02 |
DY 1.0×10 |
1000 |
10 |
3-5 |
6.73 |
7.5 |
5.5 |
7.85 |
DY 1.2×12 |
1200 |
12 |
3-5 |
5.8 |
13.1 |
11 |
13.31 |
DY 1.5×12 |
1500 |
12 |
3-5 |
4.8 |
22.3 |
15 |
21.2 |
DY 1.8×14 |
1800 |
14 |
3-5 |
3.2 |
45.8 |
30 |
48.22 |
DY 2.2×18 |
2200 |
18 |
3-5 |
3 |
50.3 |
37 |
70.43 |
DY 2.4×20 |
2400 |
20 |
3-5 |
2.83 |
78.4 |
45 |
90.43 |
DY 2.8×24 |
2800 |
24 |
3-5 |
2.59 |
97 |
75 |
147.8 |
