High Voltage Ceramic Capacitor 0402 0603 0805 etc
1. High Voltage Ceramic Capacitor Features:
1) Small size,long life,low DF and LC, reel package, suit for SMT
2) short lead time, low price
2. High Voltage Ceramic Capacitor Specifications:
1) Rated voltage:100~5000v
2) Capacitance range:1pF~10000pF Tol: +_5% +_10%,+_20%
3) Materials: NPO/COG, X7R ,Y5V/Z5U/X5R
4) Size: 0402 0603 0805 1206 1210 1812 2225 3035
High Voltage Ceramic Capacitor
Product name |
High Voltage ceramic capacitor |
Datasheets |
CC41 series |
Size |
1812 |
GT Part number |
CC41-1812CG153K630 NT |
Capacitance |
15nF |
Tolerance |
±10% |
Rated Voltage |
630V |
Dielectric Material |
COG |
Terminal material |
Nickel barrier |
Standard Package |
2000pcs/reel |
Application |
High Voltage |
RoHS Compliant |
yes |
Operating Temperature |
-55°C ~+125°C |
Table2 DIMENSIONS unit:inch/ mm
Size Code |
0402 |
0603 |
0805 |
1206 |
1210 |
1808 |
1812 |
2225 |
3035 |
|
(L×W) inch |
0.04×0.02 |
0.06×0.03 |
0.08×0.05 |
0.12×0.06 |
0.12×0.10 |
0.18×0.08 |
0.18×0.12 |
0.22×0.25 |
0.30×0.35 |
|
(L×W) mm |
1.00×0.50 |
1.60×0.80 |
2.00×1.25 |
3.20×1.60 |
3.20×2.50 |
4.50×2.00 |
4.50×3.20 |
5.70×6.30 |
7.60×9.00 |
Table3 DIELECTRIC STYLE
Dielectric Code |
CG |
HG |
LG |
PH |
RH |
SH |
TH |
UJ |
SL |
X |
B |
E |
F |
Dielectric |
COG (NP0) |
HG |
LG |
PH |
RH |
SH |
TH |
UJ |
SL |
X5R |
X7R |
Z5U |
Y5V |
High Voltage ceramic capacitor application:
1.filters, oscillators, and timing circuits
2. high voltage power supply etc.
