Type Compressor
Place of Origin Zhejiang, China
Brand Name Aitcool
Model Number RECO520SD
Certification CE, UL

with oil separator, twin piston style Refrigerant Recovery machine RECO520SD

with oil separator, twin piston style Refrigerant Recovery machine RECO520SD

with oil separator, twin piston style Refrigerant Recovery machine RECO520SD

Model RECO520SD
Refrigerants Cat.Ⅲ:R-12,R-134a,R-401C,R-406A,R-500
Cat.IV:R-22,R-401A,R-401B,R-402B,R-407C, R-407D,R-408A,R-409A,R-411A,R-411B,R-412A,R-502,R-509
Cat.V:R-402A,R-404A,R-407A,R-407B,R-410A, R-507
Power
110-127V/60Hz   220-240V 50/60Hz   110-220V 50/60Hz
Motor 1HP AC;Capacitor start
Max.Current 6A@50Hz 12A@60Hz
Compressor Twin-piston style
Refrigerant Recovery Rate
       Cat.Ⅲ       Cat.IV             Cat.V
Vapor    0.46kg/min     0.50kg/min       0.52kg/min
Liquid    3.14kg/min     3.62kg/min       3.70kg/min
Push/Pull    9.28kg/min     11.14kg/min       12.44kg/min
Recycling Rate    3.14kg/min     3.62kg/min       3.70kg/min
High Pressure Shut-off 38bar/550psi
Low Pressure Shut-off Optional
80%O.F.P.Shut-off kit Optional
Operating Temp. 0 °C-40°C
Dimensions 485mm(L)x220mm(W)x365mm(H)
Net Weight 15kg

 with oil separator, twin piston style Refrigerant Recovery machine RECO520SD

1. Recover all commonly used refrigerants (CFC,HFC, HCFC), including R410A.



2. 1/2HP&1HP, oil-less compressor recovers both vapor and liquid refrigerant quickly.



3. Heavy duty industrial grade condenser and cooling fan.



4. High pressure safety of Shut-off switch.



5. Filter/ Drier removes both moisture and acid from the refrigerant.



6. Ergonomic and compact design makes it easy to carry and use.



7. Design for residential, commercial and automotive A/C system.



8. Optional 80% capacity shut off kit to prevent from overfilling the storage tank.



9. Suitable for all the main voltage standard in the world.



10. China patent, Dual voltage refrigerant recovery, RECO-D SERIES.



11. Oil separator device for recycling refrigerant, RECO-S SERIES.
