Hig Quality Dual Voltage Auto Refrigerant Recovery Machine RECO250D

FOB Price

US$ 300 - 400 / Piece

24 Pieces(Min. Order)

Port Ningbo/Shanghai
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Type	Compressor	Place of Origin	Zhejiang, China
Brand Name	Aitcool	Model Number	RECO250D
Certification	CE, CSA, UL

Product Description

Model

RECO250D

Refrigerants

Cat.IV:R-22,R-401A,R-401B,R-402B,R-407C, R-407D,R-408A,R-409A,R-411A,R-411B,R-412A,R-502,R-509

Cat.V:R-402A,R-404A,R-407A,R-407B,R-410A, R-507

Power

110-127V/60Hz

220-240V 50/60Hz

110-220V 50/60Hz

Motor

1HP AC;Capacitor start

Max.Current

6A@50Hz 12A@60Hz

Compressor

Oil-less;air-cooled;piston style

Refrigerant Recovery Rate

Cat.Ⅲ

Cat.IV

Cat.V

Vapor

0.23kg/min 0.25kg/min 0.26kg/min

Liquid

1.57kg/min 1.81kg/min 1.85kg/min

Push/Pull

4.64kg/min 5.57kg/min 6.22kg/min

High Pressure Shut-off

38bar/550psi

Low Pressure Shut-off

Optional

80%O.F.P.Shut-off kit

Optional

Operating Temp.

0 °C-40°C

Dimensions

485mm(L)x220mm(W)x365mm(H)

Net Weight

16kg

Features:

1. Recover all commonly used refrigerants (CFC,HFC, HCFC), including R410A.

2. 1/2HP&1HP, oil-less compressor recovers both vapor and liquid refrigerant quickly.

3. Heavy duty industrial grade condenser and cooling fan.

4. High pressure safety of Shut-off switch.

5. Filter/ Drier removes both moisture and acid from the refrigerant.

6. Ergonomic and compact design makes it easy to carry and use.

7. Design for residential, commercial and automotive A/C system.

8. Optional 80% capacity shut off kit to prevent from overfilling the storage tank.

9. Suitable for all the main voltage standard in the world.

10. China patent, Dual voltage refrigerant recovery, RECO-D SERIES.

11. Voltage: 110-220V 50-60Hz.
