solar machine
Instructions:
The solar energy system is serviceable to camping, applied to the low power electrical appliance in family use. It includes: Solar panel, charge & discharges controller, direct current & alternating current and the accumulator cell.
The system has two ways of working patterns, one is solar energy charge and another is room charge and can automatically to switch between these two ways. This system can be put in the travel suitcase.
A.DC out:
This system provided 12 volts DC outlet
B.AC Out:
AC 110V/ 220V
Specification:
15W/150W
Solar panel of the case |
15W monocrystalline silicon solar panel |
Battery inside |
One pc of 12V/12Ah lead-acid battery |
Inverter inside |
Modified sinewave inveretr |
Output of the inverter |
110V/150W or 220V/150W |
Max loads could afford |
The resistant loads ----less than 150W The sensitive loads---less than 50W |
Working temperature |
-25 -- 50 |
Dimension |
465*335*180mm |
Gross weight |
10Kg |
15W/300W
Solar panel of the case |
15W monocrystalline silicon solar panel |
Battery inside |
One pc of 12V/12Ah lead-acid battery |
Inverter inside |
Modified sinewave inveretr |
Output of the inverter |
110V/300W or 220V/300W |
Max loads could afford |
The resistant loads ----less than 300W The sensitive loads---less than 100W |
Working temperature |
-25 -- 50 |
Dimension |
465*335*180mm |
Gross weight |
10Kg |
15W/500W
Solar panel of the case |
15W monocrystalline silicon solar panel |
Battery inside |
One pc of 12V/18Ah colloid battery |
Inverter inside |
Modified sinewave inveretr |
Output of the inverter |
110V/500W or 220V/500W |
Max loads could afford |
The resistant loads ----less than 500W The sensitive loads---less than 150W |
Working temperature |
-25 -- 50 |
Dimension |
465*335*180mm |
Gross weight |
10Kg |
30W/300W
Solar panel of the case |
15W monocrystalline silicon solar panel and 15W extra solar panel |
Battery inside |
One pc of 12V/12Ah lead-acid battery |
Inverter inside |
Modified sinewave inveretr |
Output of the inverter |
110V/300W or 220V/300W |
Max loads could afford |
The resistant loads ----less than 300W The sensitive loads---less than 100W |
Working temperature |
-25 -- 50 |
Dimension |
465*335*180mm |
Gross weight |
13Kg |
30W/500W
Solar panel of the case |
15W monocrystalline silicon solar panel and 15W extra solar panel |
Battery inside |
One pc of 12V/18Ah colloid battery |
Inverter inside |
Modified sinewave inveretr |
Output of the inverter |
110V/500W or 220V/500W |
Max loads could afford |
The resistant loads ----less than 500W The sensitive loads---less than 150W |
Working temperature |
-25 -- 50 |
Dimension |
465*335*180mm |
Gross weight |
15Kg |
