Metal Shell Solar Controller (10-30A)
US$ 15 - 50
MOQ: 20 Packs
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
Leacy
Model Number:
LYM
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Solar Controller With LCD Display (30-60A)US$ 40 - 100MOQ: 20 Packs -
MPPT Solar Controller (30-60A)US$ 100 - 280MOQ: 20 Packs
-
Wall Mounted Solar Controller for Project (50A)US$ 250 - 400MOQ: 2 Packs
-
Wall Mounted Solar Controller for Project (100A)US$ 250 - 500MOQ: 2 Packs
-
Wall Mounted Solar Controller for Project (150A)US$ 300 - 550MOQ: 2 Packs
Place of Origin
Zhejiang, China
Brand Name
Leacy
Model Number
LYM
Application
Charger Controller
Rated Voltage
Other, 12V/24V/36V/48V/60V/72V
Maximum Current
30A
Metal shell solar controller (10-30A)
Model |
LYM series |
||||
Rated voltage |
12/24V Auto |
36V |
48V |
60V |
72V |
Strong charging pressure |
14.8/29.6V |
44.4V |
59.2V |
74.0V |
88.8V |
Equilibrium charging |
14.5/29V |
43.5V |
58.0V |
72.5V |
87.0V |
Float charging pressure |
13.7/27.4V |
41.1V |
54.8V |
68.5V |
82.2V |
Under voltage |
10.8/21.6V |
32.4V |
43.2V |
54.0V |
64.8V |
Under recover voltage |
13.0/26.0V |
39.0V |
52.0V |
65.0V |
78.0V |
Maximum charging current |
20/25/30A |
10/20A |
10/20/30A |
10/20A |
10/20A |
Over load protection |
3s recover 1.2 times/ 10s recover 1.5 times/ over 2 times need manual recover |
||||
Working temperature |
-40℃ ~ 60℃ |
||||
Gross weight (Kg) |
0.3Kg |
||||
Dimension |
136*92*31mm |
||||
Protection level |
IP56 |
||||
