Mini Solar Controller (3-5A)
US$ 3 - 6
MOQ: 20 Packs
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
Leacy
Model Number:
LYRM
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Mini Solar Controller for Light (Time /Light /Rain Control)US$ 4 - 8MOQ: 20 Packs -
10A-20A Solar ControllerUS$ 3 - 6MOQ: 20 Packs
-
12V/24V Auto Switch Solar Controller (5-30A)US$ 6 - 15MOQ: 20 Packs
-
Water Proof Solar Controller (5-20A)US$ 8 - 15MOQ: 20 Packs
-
Booster Type/Constant Charge Current Solar Controller (water Proof) 5-20AUS$ 10 - 20MOQ: 20 Packs
Place of Origin
Zhejiang, China
Brand Name
Leacy
Model Number
LYRM
Application
Charger Controller
Rated Voltage
Other, 6V/12V
Maximum Current
5A
Mini solar controller(3-5A)
Model |
LYRM series |
Rated voltage |
6/12V |
Strong charging pressure |
7.4/14.8V |
Equilibrium charging |
7.25/14.5V |
Float charging pressure |
6.85/13.7V |
Under voltage |
5.4/10.8V |
Under recover voltage |
6.5/13.0V |
Non-load current |
≤6mA |
Charging circuit voltage drop |
≤0.2V |
Discharge circuit voltage drop |
≤0.1V |
Maximum charging current |
3A/5A |
Maximum load current |
3A/5A |
Controller protection |
Overcharge/Over discharge/Over current/Short circuit/reversed |
Charge mode |
PWM |
Using elevation |
≤5500m |
Working temperature |
-20℃ ~ 55℃ |
Gross weight (Kg) |
0.05Kg |
Net weight (Kg) |
0.035Kg |
Dimension |
79.5*52*21.5mm |
Protection level |
IP22 |
