US$ 1,000 - 3,000 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Hunan, China
Brand Name:
SOLLROC
Model Number:
RE547
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai Shenzhen any ports
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Hunan, China
Brand Name SOLLROC
Model Number RE547
Type Other, Hammer
Machine Type Drilling Tool
Certification API
Material Other, carburized steel
Processing Type Other, Heat treatment + Machining Process
Use Well Drilling
Application

RC hammers and bits are used in hole drilling in mines, hydrology and water well, geothermal well, geothermal air conditioning well, geologic exploration, complicated gravel stratum, etc

Especial suitable for complicated formation (Formation loose, difficult to drilling and unstable of hole wall), exhausting for deep hole, environment protection.

Futures

- Manufactured using premium hardened metals for long life;
- Maximum material recovery, up to 98%;
- No cross contamination of samples;
- Handles injection of water, foam, oil, and polymers without performance loss;
- Delivers maximum drilling under water.

Product Description


5.5" RC hammer RE547 Technical data:

Length (without bit)
1270mm
Weight (without bit)
71.0kg
Out dia. of hammer
124.5mm
Bit shank
RE547
Hole range
130-146mm
Connection thread
4.5" Remet / 4.5" Metzke
Working pressure
10-30 bar
Air consumption
1.7 Mpa
16 m3/min
2.4 Mpa
22 m3/min
3.0 Mpa
28 m3/min

We adjust button number, button configuration, button diameter to get ultra performance and reduce the drilling cost for you according to your rock formation situation.

Detailed Images
Packing & Delivery

Ply-wooden cases


Ply-wooden cases + pallet


Related RC hammers

3" RC hammers model RE531


4" RC hammers model RE004


4.5" RC hammers model RE542


4.5" RC hammers model RE543


5" RC hammers model PR40


5" RC hammers model RE545


5.5" RC hammers model PR52


5.5" RC hammers model PR54


5.5" RC hammers model RE547


6" RC hammers model RC6A

Related products

DTH hammers >>


DTH bits >>

RC hammers >>

.

RC bits > >


Button bits > >


ODEX and concentric system >>
