700ma isolated constant current led tube driver small size
Product parameters:
Model |
Input voltage (vAC) |
Working Frequency (Hz) |
Output voltage (vDC) |
Output Current |
power (Watt) |
Working Temp. |
Protection grade |
SMT- 050-0300CW |
100-265vAC |
47~63Hz |
25-50v |
300mA |
15W |
-25~50°C |
IP20 |
SMT-025-0700CW |
100-265vAC | 47-63Hz | 12-25V | 700mA | 17.5W | -25~50°C | IP20 |
SMT-030-0700CW |
100-265vAC | 47-63Hz | 20-30V | 700mA | 21W | -25~50°C | IP20 |
SMT-020-0900CW |
100-265vAC | 47-63Hz | 10-20V | 900mA | 18W | -25~50°C | IP20 |
- High efficiency,save energy ,protected environment
- High stability and low ripple, increase light efficiency and decrease light attenuation
- Meet to safety standard and EMC
- Assure LED stability long lift and light efficiency by constant voltage
- Passed high ,low temperature and waterproof testing.
- Integrity protection,over loading, over voltage over current
- 8Hrs and 100% full load burn-in test.
- 2 years warranty
- (We promise to replace new ones to you if there is any defective happen during the warranty period)
Environment :
- Working Temperature : -25 ~ +50°C
- Working Humidity : 20 ~ 90% RH non-condensing
- Storage Temp. , Humidity : -40 ~ +80°C , 10 ~ 95% RH
- TEMP. Coefficient : ±0.03%/°C (0 ~ 50°C)
- Vibration : 10 ~ 500Hz, 2G 10min./1cycle, period for 60min. each along X, Y, Z axes
Safety :
- Safety Standards : IEC 61347 –2–11 , IEC 61347 –1 , IEC 60529 , IP67 approved
- Withstand Voltage : I/P-O/P: 3000KVAC
- Isolation Resistance : I/P-O/P:100M Ohms/500VDC
Applications:
- indoor LED illuminating lights, LED Neon
- LED urban Decoration,LED Lighting Advertising
- LED Display, Safety Protection Apparatus
- Telecommunications, Networks
- Vehicle Lights, Controller Panels
Triac Dimmable Constant Current & Constant Voltage LED Driver
0-10V Dimmable Constant Current & Constant Voltage LED Driver
DALI Dimming Constant Current & Constant Voltage LED Driver
Packing
| Packing | |||||||
| N.W./pcs | G.W/ctn | Qty/ctn | Carton Size(mm) | ||||
| 700ma isolated constant current led tube driver small size | |||||||
| 90g/pcs | 5.5kg/ctn | 100pcs | 299*224*176 mm | ||||
