External led power supply 7 - 9W 24v 350ma led driver for led bulb led spot light
| MODEL | SMT-032-0320CW | SMT-026-0350CW | |
| OUTPUT | DC VOLTAGE | 23-34V | 15v-26v |
| RATED CURRENT | 320mA | 350mA | |
| CURRENT RANGE | ±20mA | ±20mA | |
| RATED POWER | 7~10Watt | 6~9Watt | |
| RIPPLE&NOISE(max) | <500mV | <500mV | |
| NO-LOAD VOLTAGE | <39V | <39V | |
| INPUT | VOLTAGE RANGE | 100~265VAC | 100~265VAC |
| FREQUENCY RANGE | 47~63Hz | 47~63Hz | |
| POWER FACTOR(Typ.) | |||
| EFFICIENCY(Typ.) | >82% | >82% | |
| AC CURRENT(Typ.) | 0.12A/100~220VAC | 0.12A/100~220VAC | |
| PROTECTION | Short circuit |
Protection type:Hiccpe mode,recovers automatically after condition is removed |
|
| Overload | |||
| ENVIRONMENT | WORKING TEMP. | -30~+50℃ (Refer to output load derating curve) | |
| INGRESS PROTECTION | IP67 design for indoor or outdoor installations | ||
| STORAGE TEMP | -40~+80℃ | ||
| SAFETY&EMC | SAFETY STANDARDS | EN61347-1;EN61347-2-13;SELV;IP67 approved | |
| WITHSTAND VOLTAGE | I/P-O/P:2KVAC I/P-FG:2KVAC O/P-FG:0.5KVAC | ||
| EMC Test Standards | EN55015;EN61000-3-2;EN61000-3-3; | ||
| EN61547;EN61000-4-2,3,4,5,6,8,11; | |||
- All parameters NOT specially mentioned are measured at 110,220VAC input,rated load and 25℃ of ambient temperature.
- Ripple&noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf&47uf parallel capacitor.
- Tolerance:includes set up tolerance,line regulation and load regulation.
| |
|
What's the other type power supply do you have???
Answer: We specialized in constant voltage & current LED drivers, 010v/triac/DALI dimmable led drivers, enclosure power suppliers, power adapters.
|
constant volatge led drivers
|
AC-DC adapter
|
switching power supplies
|
|
triac dimmable led drivers
|
0-10v dimmable led drivers
|
DALI dimmable led drivers
|
Why choose Quanzhou Smarts Electronic & Technology Co.,Ltd ???
1). Our major markets are in EU & North America,it takes about 85% markets share,that to say we do high quanlity power suppliers only.
2). Most of our products are approved with UL/CE/Rohs approval, our ULfile#E365202.
3). We give 2 years warranty
4). We accept trial orders begining..
5). We have an area of 2000 square meters factory, about 300-500 production staff. ..
Website:
our team:
certifications:
CE, UL/CUL, ROHS approval.
our market
Our major markets are in EU & North America,it takes about 70% markets share. view transaction history
factory & equipments view:
Our service & FAQ
Q1. What's the trade terms you can do??
A1: We accept EXW,FOB..(Optional)
Q2. What's shipping mode can we choose?
A2: Express, Ocean and air transportation (optional).
Q3. What's the MOQ?
A3: Our MOQ is 10pcs. better price for large quantity;
Q4. What can you do if the product is broken?
A4: We promise to replace new ones to you if there is any defective happen during the warranty period.
Q5. Can i get products with my own logo??
A5: Sure, you can, MOQ is 500pcs.
Q6. Can i get a sample for testing??
A6: Sure, but sample fees should be charged on your account.
Q7. What's the mormal lead time??
A7: 7 working days for samples, 15 working days for mass production.
Q8. What's the payment conditon?
A8: All are paid before production or 30% deposit and 70% before delivery (optional)
Q9. What's the Payment do you have?
A9: We accept payment be sent via T/T, L/C, Trade Assurance, WESTERN UNION, PAYPAL.
