ul Led Tube Dali Constant Current Dimmable Driver

ul Led Tube Dali Constant Current Dimmable Driver thumbnail-1
ul Led Tube Dali Constant Current Dimmable Driver thumbnail-2
ul Led Tube Dali Constant Current Dimmable Driver thumbnail-3
ul Led Tube Dali Constant Current Dimmable Driver thumbnail-4
ul Led Tube Dali Constant Current Dimmable Driver thumbnail-5
ul Led Tube Dali Constant Current Dimmable Driver thumbnail-6
ul Led Tube Dali Constant Current Dimmable Driver photo-1
ul Led Tube Dali Constant Current Dimmable Driver photo-2
ul Led Tube Dali Constant Current Dimmable Driver photo-3
ul Led Tube Dali Constant Current Dimmable Driver photo-4
ul Led Tube Dali Constant Current Dimmable Driver photo-5
ul Led Tube Dali Constant Current Dimmable Driver photo-6
US$ 28 - 31 MOQ: 50 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Fujian, China
Brand Name:
SMARTS
Model Number:
SMT-038-2100CM
Contact Supplier Request Quote Chat Now
Quanzhou Smarts Electronic & Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
xiamen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Fujian, China
Brand Name SMARTS
Model Number SMT-038-2100CM
Output Power Other, 79Watt
Output Type Single
Input Voltage Other, 100-265vDC
Output Voltage 20-38V
Output Frequency 47-63Hz
Output Current 2100mA

ul led tube dali constant current dimmable driver

Product Description
 Item No.   Input
voltage(vAC) 		Working
Frequency(Hz) 		Output
voltage(vDC)

Output

Current(mA)

 power
(Watt) 		Working
Temp. 		IP rate
SMT-080-1050CM 100-265vAC 47~63Hz 45-80V 1050mA 84W -25~50°C IP67
SMT-067-1200CM 100-265vAC 47~63Hz 35-67V 1200mA  80W ‘-25~50°C IP67
SMT-057-1400CM 100-265vAC 47~63Hz 35-57V 1400mA  80W -25~50°C IP67
SMT-040-2000CM 100-265vAC 47~63Hz 20-40V 2000mA  80W -25~50°C IP67
SMT-038-2100CM 100-265vAC 47~63Hz 20-38V 2100mA  79W -25~50°C IP67
SMT-034-2400CM 100-265vAC 47~63Hz 18-34V 2400mA  81W -25~50°C IP67

 Specifications:

  • Dimming mode: DALI dimmable
  • Power factor: >0.90
  • Effi.: >88%
  • Pack weight:  13.2kg/ctn
  • Produt cord:18AWG*20CM
  • CE, UL&CUL, ROHS approval
  • 3 years warranty
  • (We promise to replace new ones to you if there is any defective happen during the warranty period)

Features:

  • High efficiency,save energy ,protected environment.
  • Output constant current
  • Range 100-265VAC
  • Built-in PFC function
  • Efficiency > 90%
  • Dimming function:DALI with better compatibility
  • High stability and low ripple, increase light efficiency and decrease light attenuation.
  • Meet to safety standard and EMC
  • Assure LED stability long lift and light efficiency by constant current.
  • Protections:Short circuit/Overload/Over temperature
  • Cooling by free air convection
  • 100% full load burn-in test.
  • Suitable for LED lighting applications by PWM output
  • Compliance to worldwide safety regulations for lighting
  • Suitable for dry/damp/wet locations

Environment:

  • Working temp: -30~+50℃ (Refer to output load derating curve)
  • Working humidity: 20~99% RH non-condensing(Waterproof)
  • Storage temp. humidity:  -40~+80℃,10~99%RH

Safety:

  • Safety Standards :  EN61347-1 EN61347-2-13 IP40
  • Withstand Voltage : I/P-O/P:3.75KVAC I/P-FG:1.88KVAC O/P-FG:0.5KVAC
  • Isolation Resistance : I/P-O/P I/P-FG O/P-FG:100MΩ/500VDC/25℃/70%RH

Application:

  • indoor LED illuminating lights, LED Neon
  • LED urban Decoration,LED Lighting Advertising
  • LED Display, Safety Protection Apparatus
  • Telecommunications, Networks
  • Vehicle Lights, Controller Panels

ul led tube dali constant current dimmable driver

Related Products

Triac Dimmable Constant Current & Constant Voltage  LED Driver

ul led tube dali constant current dimmable driver

ul led tube dali constant current dimmable driver

0-10V Dimmable Constant Current & Constant Voltage LED Driver

ul led tube dali constant current dimmable driver

ul led tube dali constant current dimmable driver

DALI Dimming Constant Current & Constant Voltage LED Driver

ul led tube dali constant current dimmable driver

ul led tube dali constant current dimmable driver



Packaging & Shipping
Packing
N.W./pcs G.W/ctn Qty/ctn Carton Size(mm)
ul led tube dali constant current dimmable driver
1100g/pcs 13.2kg/ctn 10pcs 324*298*176mm

 Packing:
ul led tube dali constant current dimmable driver

Shipping

ul led tube dali constant current dimmable driver

Company Information
Quanzhou Smarts Electronic & Technology Co.,Ltd (SMARTS INDUSTRIAL (HOLDING) CO LTD) was founded in 1998. The company is located in a developed economy, abundant resources, beautiful scenery of Quanzhou city Licheng district town pontoon, the company has an area of 2000 square meters, production workshop, warehouse, office, living facilities complete with. With the development of society, human increasing awareness of "green energy, environmental protection, save energy" becomes...View this Supplier's Website

Our team                                                                                                                                                               ul led tube dali constant current dimmable driver


Factory & Equipments view
ul led tube dali constant current dimmable driver

 CE UL/cUL ROHS Certification

ul led tube dali constant current dimmable driver

Our Services
  • We are UL/cUL audited LED drivers/power supplies enterprise in China
  • Alibaba assessed 6 years Gold Supplier and more than 10 years LED industrial  experience. It will guarantee your order 100% safe
  • Price is negotiable if you have large quantity demand
  • 100% QC inspection Before Shipping
  • Best Quality & Best Service with Competitive price
  • Shipping will be the most economical for you and freight cost is informed in advance
  • consideration.decision for the shipping terms will be made according to your requirements
  • We have our engineer team, if you have any question about your LED applications, let  us know freely, we will give you the best solution
  • Our trade manager is online 12 hours. and we will reply your inquiry within 8 hours
  • OEM design & OEM packing welcome
  • Samples will be ready within 7 working days
FAQ

Q1. What's type power supply do you have?

A1: We specialized in constant voltage & current LED drivers, 0-10v/triac/DALI

       dimmable led drivers, enclosure power suppliers, power adapters.



Q2. What's shipping mode can we choose?

A2:1.FedEx/DHL/UPS/TNT/Express for samples;

      2. By Air or by Sea for batch goods, for FCL; Airport/ Port receiving;

      3. Customers specifying freight forwarders or negotiable shipping methods!



Q3. What's the MOQ?

A3: Our MOQ is 500pcs, but we accept your trail order/small order, no problem.



Q4. What can you do if the product is broken?

A4: We promise to replace new ones to you if there is any defective happen during

      the warranty period, but we need pictures or video to prove the defective comes

      from our quality problem.



Q5. How about the protection of product?

A5: Most of our products have protection of short-circuit, overload, over voltage,

       over current and reserve polarity. About the specific product, please consult

       our sales stuff.



Q6. How about the transportation?

A6: For small order,express will be best.And for bulk order,sea ship way is best but

       take much time. For urgent orders,we suggest via air to airport plus our ship partner

       send to your door. We will cooperate with your choice.



Q7. What's the Payment do you have?

A7: To assure you the maximum comfort and satisfaction, Currently, you can pay via

        T/T, L/C, WESTERN UNION, PAYPAL. More payment options will be added in the

        near future.
