dali dimming ul 230v 12v dc 10a 120w isolation transformer
Product parameters:
| Model | SMT-012-120VM | SMT-024-120VM | |||||||||
| Single Output features | Constant voltage | 12vDC | 24vDC |
|
|||||||
| output current | 10A | 5A | |||||||||
| output power | 120watt | 120watt | |||||||||
| Ripple & Noise | 250mV | ||||||||||
| Current Regulation | ±3% | ||||||||||
| Starting time | 1000mS/230Vac, 3000mS/110Vac | ||||||||||
| Input | Voltage range | 100Vac-265Vac | |||||||||
| Frequency range | 47Hz-63Hz | ||||||||||
| Power factor | PF>0.93/230Vac,PF>0.92/110Vac | ||||||||||
| Efficiency | 87%/110Vac , 86%/230Vac | ||||||||||
| Inrush Current | 20A/110Vac, 40A/230Vac | ||||||||||
| Leakage Current | <1mA/120Vac,240Vac | ||||||||||
| Protection | short circuit | ||||||||||
| Single Protection,Hiccup ,recovery after the fault removed. | |||||||||||
| Over voltage | Protection mode:Limit highest voltage, recovery after the fault removed. | ||||||||||
| Over temperature | 105oC±5 oC ( Internal radiator's temperature) | ||||||||||
| over load |
Protection mode:Closed Output voltage,recovery after temperature automatic recovery. |
||||||||||
Features:
- Output constant voltage
- Input range:100-265vAC /170-265vAC
- Built-in PFC function
- Efficiency > 85%
- Protections:Short circuit/over Voltage
- Fully isolated Aluminum housing
- Easy installation
- Cooling by free air convection
- Work with leading edge and trailing edge TRIAC dimmers
- Strong compatibility, flicker-free dimming
- Suitable for LED lighting and moving sign applications
- Compliance to worldwide safety regulations for lighting
- CE,UL/cUL, RoHS approval
- 3 years warranty (We promise to replace new ones to you if there is any defective happen during the warranty period)
Environment :
- Working Temperature : -25 ~ +50°C
- Working Humidity : 20 ~ 90% RH non-condensing
- Storage Temp. , Humidity : -40 ~ +80°C , 10 ~ 95% RH
- TEMP. Coefficient : ±0.03%/°C (0 ~ 50°C)
- Vibration : 10 ~ 500Hz, 2G 10min./1cycle, period for 60min. each along X, Y, Z axes
Safety :
- Safety Standards : IEC 61347 –2–11 , IEC 61347 –1 , IEC 60529 , IP67 approved
- Withstand Voltage : I/P-O/P: 3000KVAC
- Isolation Resistance : I/P-O/P:100M Ohms/500VDC
| dali dimming ul 230v 12v dc 10a 120w isolation transformer | |||
| Net weight (g) | Gross Weight/ctn | Qty/ctn | Carton size(mm) |
| 1300g | 15 kg | 10 pcs | 329*279*176mm |
| |
|
