Home > Electrical & Electronics > Power Supply & Distribution > Switching Power Supply > 277V LED Driver

277V LED Driver

Name: 277V LED Driver
Brand: SMARTS
SKU: 134456133

Negotiable MOQ: 500 Pieces (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Place of Origin:

Fujian, China

Brand Name:

SMARTS

Model Number:

SMT-040-0500CW

Contact Supplier Request Quote Chat Now

Quanzhou Smarts Electronic & Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

xiamen

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Fujian, China

Brand Name SMARTS

Model Number SMT-040-0500CW

Output Power Other, 18 20, 25, 28 watt

Output Type Single

Input Voltage Other, 100-265V/170-305vAC

Output Voltage 10-60vDC

Output Frequency 47-63Hz

Output Current 350mA,500mA, 700mA, 750mA, 900mA

Specifications

277vAC LED power supply
1) Efficiency>84%
2) Input:100-265V,170-305vAC
3) Warranty:2 year
4) CE,ROHS,UL approval

(CE/UL approved 277VAC waterproof CC LED driver )

(input range: 100~265VAC/170~305vAC)

Features
• Case material--Aluminum
• waterproof Rate: IP67

• Efficiency>84%

• CE,ROHS,UL/cUL approval

• Warranty: 2 years

(Note: If there is any defective units happen during the warranty period,we promise to replace new ones to you)

General Specification:
•  High efficiency,save energy ,protected environment .
•  High stability and low ripple, increase light efficiency and decrease light attenuation.
• Meet to safety standard and EMC .
•  Assure LED stability long lift and light efficiency by constant voltage.
• Passed high ,low temperature and waterproof testing.
• Integrity protection: over loading, over voltage ,over current .
• 12Hrs and 100% full load burn-in test.

Product parameters:

Model	Input voltage (AC V)	Working Frequency (Hz)	Output voltage (DC V)	Output Current (mA)	Output power (DC W)	Working Temp.	Protection grade
SMT-060-0350CW	100-265v 170-305v	47-63HZ	45-60V	350mA	18W	-25~50°C	IP67
SMT-040-0500CW	100-265v 170-305v	47-63HZ	24-40V	500mA	20W	-25~50°C	IP67
SMT-030-0700CW	100-25v 170-305v	47-63HZ	20-30V	700mA	21W	-25~50°C	IP67
SMT-020-0900CW	100-265v 170-305v	47-63HZ	10-20V	900mA	18W	-25~50°C	IP67

Application:

Our products are widely used in various industries, such as outdoor LED illuminating lights, LED Neon, LED City Decoration, LED Lighting Advertising, LED Display, Safety Protection Apparatus, Telecommunications, Networks, Vehicle Lights, Controller Panels, etc.
